Product Details:
|
| Sample: | Free | Standard: | ASTM / GB / JIS / DIN |
|---|---|---|---|
| Surface: | Bright | State: | Soft Hard |
| Color: | Brown | ||
| High Light: | nickel copper alloy,copper and nickel alloy |
||
Chemical Content, %
| Ni | Mn | Fe | Si | Cu | Other | ROHS Directive | |||
| Cd | Pb | Hg | Cr | ||||||
| 1 | - | - | - | Bal | - | ND | ND | ND | ND |
Mechanical Properties
| Max Continuous Service Temp | 200℃ |
| Resisivity at 20℃ | 0.03±10%ohm mm2/m |
| Density | 8.9 g/cm3 |
| Thermal Conductivity | <100 |
| Melting Point | 1090℃ |
| Tensile Strength,N/mm2 Annealed,Soft | 140~310 Mpa |
| Tensile Strength,N/mm2 Cold Rolled | 280~620 Mpa |
| Elongation(anneal) | 25%(min) |
| Elongation(cold rolled) | 2%(min) |
| EMF vs Cu, μV/ºC (0~100ºC) | -8 |
| Micrographic Structure | austenite |
| Magnetic Property | Non |
Application of CuNi1
CuNi1 low resistance heating alloy is widely used in low-voltage circuit breaker, thermal overload relay, and other low-voltage electrical product. It is one of the key materials of the low-voltage electrical products. The materials produced by our company have the characteristics of good resistance consistency and superior stability. We can supply all kinds of round wire, flat and sheet materials.
Main Technical Parameter:
| main property | type |
NC003 CuNi1 |
NC005 CuNi2 |
NC010 CuNi6 |
NC012 CuNi8 |
NC012 CuMn3 |
NC015 CuNi10 |
NC020 CuNi14 |
NC025 CuNi19 |
NC030 CuNi23 |
NC035 CuNi30 |
NC040 CuNi34 |
NC050 CuNi44 |
| main chemical composition | Ni | 1 | 2 | 5 | 8 | / | 10 | 14.2 | 19 | 23 | 30 | 34 | 44 |
| Mn | / | / | / | / | 3 | / | 0.3 | 0.5 | 0.5 | 1.0 | 1.0 | 1.0 | |
| Cu | rest | rest | rest | rest | rest | rest | rest | rest | rest | rest | rest | rest | |
| working temperature | 200 | 200 | 220 | 250 | 200 | 250 | 300 | 300 | 300 | 350 | 350 | 400 | |
| temperature coefficient of resistance | <100 | <120 | <60 | <57 | <38 | <50 | <38 | <25 | <16 | <10 | -0 | <-6 | |
| melting point | 1085 | 1090 | 1095 | 1097 | 1050 | 1100 | 1115 | 1135 | 1150 | 1170 | 1180 | 1280 | |
| tensile mpa | >210 | >220 | >250 | >270 | >290 | >290 | >310 | >340 | >350 | >400 | >400 | >420 | |
| elongation% | >25 | >25 | >25 | >25 | >25 | >25 | >25 | >25 | >25 | >25 | >25 | >25 | |
| resistivity | 0.03±10% | 0.05±10% | 0.10±10% | 0.12±10% | 0.12±10% | 0.15±10% | 0.20± 5% | 0.25± 5% | 0.30± 5% | 0.35± 5% | 0.40± 5% | 0.49± 5% | |
| density g/cm3 | 8.9 | 8.9 | 8.9 | 8.9 | 8.8 | 8.9 | 8.9 | 8.9 | 8.9 | 8.9 | 8.9 | 8.9 | |
| conductivity | 145 | 130 | 92 | 75 | 84 | 59 | 48 | 38 | 33 | 27 | 25 | 23 | |
Main Advantage and Application:
Copper Nickel Alloys Wire/Strip/Sheet Principally destined for the manufacturing of low temperatures electric resistances so as heating cables, shunts, resistances for automobile,they have a maximum operating temperature of 752°F.
They do not therefore intervene in the field of resistances for industrial furnaces.Those are alloys of chemical composition copper + nickel with addition of manganese with a low resistivity (from 231.5 to 23.6 Ohm.mm2/ft).
Service
1 . fine after-sale services
2 . small order accepted
3 . samples available
