Product Details
Place of Origin: Sahnghai China
Brand Name: TANKII
Certification: ISO:9001 RoHS
Model Number: C71000
Payment & Shipping Terms
Minimum Order Quantity: 100Kilograms
Price: USD+10 - 30 +kilograms
Packaging Details: Standard export seaworthy packing,wooden pallet,wooden case or be required
Delivery Time: 7 - 10 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200+TonS+per month
Size: |
0.01 - 5mm * 0.5 - 600m |
Standard: |
ASTM / GB / JIS / DIN |
Surface: |
Bright |
State: |
Soft Etc. |
Size: |
0.01 - 5mm * 0.5 - 600m |
Standard: |
ASTM / GB / JIS / DIN |
Surface: |
Bright |
State: |
Soft Etc. |
Copper Cu: margin
Ni + Co Ni + Co: 18.0 ~ 20.0
Zinc Zn: ≤0.3
Lead Pb: ≤0.005
Phosphorus P: ≤0.01
Iron Fe: ≤0.5
Manganese Mn: ≤0.5
Si Si: ≤0.15
Antimony Sb: ≤0.005
Sulfur S: ≤0.01
Arsenic As: ≤0.010
Carbon C: ≤0.05
Bi Bi: ≤0.002
Mg Mg: ≤0.05
NOTE: ≤1.3 (impurity)
Mechanical Properties:
Tensile strength σb (MPa): ≥295
Elongation δ10 (%): ≥20
Note: The wire tensile mechanical properties at room temperature
Sample size: diameter 1.0 to 0.50
Heat Specifications: Casting temperature 1280 ~ 1300 ℃; annealing temperature of 600 ~ 780 ℃; thermal processing temperature of 980 ~ 1030 ℃; to eliminate the stress of low temperature annealing temperature of 250 ℃.
1 ) Thickness: 0.035- 2.5mm
2 ) Width: 610mm max. Coil weight: 3 ton Max
3 ) Grade: B19,B25,C71000,C71300,CN105,CUNI25 ,C1100 / C1020 / C1220
4 ) Chemical Composition:C1100: Cu >99.90% C1020: Cu >99.96% C1220: Cu >99.97%; P 0.015-0.04%
5 ) Oxygen content:C1100: O < 500PPM C1020: O < 50PPM
6 ) Temper: O, 1/4H, 1/2H, H O: HV<70; 1/4H:HV 65-85; 1/2H:HV 80-100; H:HV >100
7 ) Electric 20°CConductivity:C1100/C1020 >97% ;C1220 >80%
| Product | Grade | Temper | Thickness | Width |
| Brass Strip | C2600 C2680 C2801 | O, 1/4H, 1/2H, 3/4H, H, EH, SH | 0.01-5.0mm | 1-610mm |
| Bronze Strip | C5191 C5210 C5102 C5212 | 1/2H, 3/4H, H, EH, SH | 0.01-4.0mm | 1-610mm |
| Copper Tape | C2600 C2680 C2801 | O, 1/4H, 1/2H, H | 0.015-5.0mm | 1-610mm |
| Reflow Tin Plated Copper Strip | C7541 C7521 C7701 | O,H | 0.01-22mm | max 600mm |
| Copper Clad Metal Strip Gilding Metal | CuZn90,CuZn10,CuZn85 | F18,F11 | 0.01-3.55mm | 1-600mm |
| Copper Beryllium Strips | C17200 C17000 C17300 C17500 C17510 | TB00 TD01-04 TF00 TH01-04 TM00-08 | 0.012-2.0mm | 1-600mm |
| Oxygen-Free Copper Strip | C1020 C1201 C1220 | O, 1/4H, 1/2H, Hl | 0.01-2mm | max 600mm |
| Copper Nickel Zinc Strips | C7541 C7521 C7701 | O 1/4H 1/2H 3/4H H EH SH | 0.015-22mm | max 600mm |
| Copper Clad Steel Strip | C1020 C1201 C1220 | O, 1/4H, 1/2H, Hl | 0.01-2.5mm | 1-600mm |
| Brass Clad Steel Strip Coil | C2600 C2680 C2801 | H65 H90 | 0.015-5.0mm | 1-610mm |
| Copper Clad Aluminum Busbar | 1070 aluminum; C1020 C1201 C1220 copper | hard,soft, semi-hard | 0.01-12mm | 1-600mm |
copper pvc sheet roll
price C71000,C71500,C71520,C71640,C72200
| Item | Copper plate ,Copper sheet,handmade copper plate ,copper bright plate |
| Material | C2200,C2600,C2680,C2800,T1,T2 etc |
| Standard |
GB/T5231-2001.GB/T1527-2006.JISH3100-2006,JISH3250-2006,JISH3300-2006, ASTMB152M-06,ASTMB187,ASTMB75M-02,ASTMB42-02,etc |
| Size |
Thick:0.1mm~200mm Width:10-2500mm Length:1-12m,rolled,or as required |
| Application |
copper sheet Can be made to do all sorts of deep drawing and bending stress components, such as manufacturing pins,rivets,gasket,nuts,conduits,the barometer spring,screen,radiator parts, etc |
Shanghai Tankii Alloy Material Co., Ltd.specialized in production of Copper Alloy, pure nickel and other precision alloy materials in the form of round wire, ribbon wire, sheet, tape, strip, rod and plate.
We’ve already got ISO9001 quality system certificate and approval of ISO14001 environmental protection system.
We own a complete set of advanced production flow of refining, cold reduction, drawing and heat treating etc. We also proudly have independent R&D capacity.
Shanghai Tankii Alloy Material Co., Ltd has accumulated lots of experiences over nine years in this field. During nine years, more than 60 management elites and high science and technology talents were employed.They participated in every walk of the company life, which make our company keep blooming and invincible in the competitive market.
Based on the principle of “first quality, sincere service”, our managing ideology is pursuing technology innovation and creating the top brand in the alloy field. We persist in Quality - the foundation of the survival. It is our forever ideology to serve you with full heart and soul. We committed to provide customers all over the world with high-quality, competitive products and perfect service.
Our products, such us nichrome wire, nichrome strip, fecral wire, fecral strip, thermocouple wire, nickel wire, nickel strip have been exported to Europe, USA, India, Southest Asia, South America,etc.
