0.18mm 0.25mm Ni80cr20 Nichrom Wire For Nickel Mesh

Name: 0.18mm 0.25mm Ni80cr20 Nichrom Wire For Nickel Mesh
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: Ni80cr20
Price: 25.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Tankii

Certification: ISO9001

Model Number: Ni80cr20

Document: Tankii Alloy Catalog.pdf

Payment & Shipping Terms

Minimum Order Quantity: 10kg

Price: 20-30USD/KG

Packaging Details: case

Delivery Time: 10-15days

Payment Terms: L/C,D/A,D/P,T/T,Western Union

Supply Ability: 5000kg/Month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                      0.18mm Ni80cr20 nichrom wire, 0.25mm nickel mesh wire, Ni80cr20 copper nickel alloy wire


TypeType:	Nickel Wire	Chemical Composition:	Ni 76%
Range Of Application:	Resistor, Heater,Chemical	The Highest Use Temperature:	1400
Elongation:	>=20%	Specification:	0.01-8.0mm

TypeType:	Nickel Wire
Chemical Composition:	Ni 76%
Range Of Application:	Resistor, Heater,Chemical
The Highest Use Temperature:	1400
Elongation:	>=20%
Specification:	0.01-8.0mm

Description

0.18mm 0.25mm Ni80cr20 Nichrom Wire For Nickel Mesh

0.18mm 0.25mm Ni80Cr20 Nichrom Wire For Nickel Mesh

Description

Chemical Composition and Propertes:
Propertes/Grade		NiCr 80/20	NiCr 70/30	NiCr 60/15
Main Chemical Composition(%)	Ni	Bal.	Bal.	55.0-61.0
	Cr	20.0-23.0	28.0-31.0	15.0-18.0
	Fe	≤ 1.0	≤ 1.0	Bal.
Max Working Temperature(ºC)		1200	1250	1150
Resistivity at 20ºC(μ Ω · m)		1.09	1.18	1.12
Density(g/cm3)		8.4	8.1	8.2
Thermal Conductivity(KJ/m· h· ºC)		60.3	45.2	45.2
Coefficient of Thermal Expansion(α × 10-6/ºC)		18	17	17
Melting Point(ºC)		1400	1380	1390
Elongation(%)		> 20	> 20	> 20
Micrographic Structure		austenite	austenite	austenite
Magnetic Property		nonmagnetic	nonmagnetic	nonmagnetic

Propertes/Grade		NiCr 35/20	NiCr 30/20	Karma	Evanohm
Main Chemical Composition(%)	Ni	34.0-37.0	30.0-34.0	Bal	Bal
	Cr	18.0-21.0	18.0-21.0	19.0-21.5	19.0-21.5
	Fe	Bal.	Bal.	2.0-3.0	-
Max Working Temperature(ºC)		1100	1100	300	1400
Resistivity at 20ºC (μ Ω · m)		1.04	1.04	1.33	1.33
Density(g/cm3)		7.9	7.9	8.1	8.1
Thermal Conductivity (KJ/m· h· ºC)		43.8	43.8	46	46
Coefficient of Thermal Expansion(α × 10-6/ºC)		19	19	-	-
Melting Point(ºC)		1390	1390	1400	1400
Elongation(%)		> 20	> 20	10-20	10-20
Micrographic Structure		austenite	austenite	austenite	austenite
Magnetic Property		nonmagnetic	nonmagnetic	nonmagnetic	nonmagnetic

Chemical Composition	Nickel 80%, Chrome 20%
Condition	Bright/Acid white/Oxidied Color
Diameter	0.018mm~1.6mm in spool, 1.5mm-8mm packing in coil, 8~60mm in rod
Nichrome Round Wire	Diameter 0.018mm~10mm
Nichrome Ribbon	Width 5~0.5mm, thickness 0.01-2mm
Nichrome Strip	Width 450mm~1mm, thickness 0.001m~7mm
Diameter	1.5mm-8mm packing in coil, 8~60mm in rod
Grade	Ni80Cr20, Ni70/30, Ni60Cr15, Ni60Cr23, Ni35Cr20Fe, Ni30Cr20 Ni80, Ni70,Ni60, Ni40,
Advantage	The metallurgical structure of nichrome confers them a very good plasticity when cold.
Characteristics	Stable performance; Anti-oxidation; Corrosion resistance; High temperature stability; Excellent coilforming ability; Uniform and beautiful surface condition without spots.
Usage	Resistance heating elements;Material in metallurgy, Household appliances;Mechanical manufacturing and other industries.

Resistance Wires
RW30	W.Nr 1.4864	Nickel 37%, Chrome 18%, Iron 45%
RW41	UNS N07041	Nickel 50%, Chrome 19%, Cobalt 11%, Molybdenum 10%, Titanium 3%
RW45	W.Nr 2.0842	Nickel 45%, Copper 55%
RW60	W.Nr 2.4867	Nickel 60%, Chrome 16%, Iron 24%
RW60	UNS NO6004	Nickel 60%, Chrome 16%, Iron 24%
RW80	W.Nr 2.4869	Nickel 80%, Chrome 20%
RW80	UNS NO6003	Nickel 80%, Chrome 20%
RW125	W.Nr 1.4725	Iron BAL, Chrome 19%, Aluminium 3%
RW145	W.Nr 1.4767	Iron BAL, Chrome 20%, Aluminium 5%
RW155		Iron BAL, Chrome 27%, Aluminium 7%, Molybdenum 2%
