Type K N E T C Thermocouple Bare Wire for Extension Cable

Name: Type K N E T C Thermocouple Bare Wire for Extension Cable
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: thermocouple wire
Price: 40 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Tankii

Certification: -

Model Number: thermocouple wire

Document: Tankii Alloy Catalog.pdf

Payment & Shipping Terms

Minimum Order Quantity: 50kg

Price: 40USD

Packaging Details: case

Delivery Time: 15days

Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram

Supply Ability: 500ton/year

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                          TC wire thermocouple ASTM B206, thermocouple wire DIN 17664, copper nickel alloy wire EN 12163


Shape:	Strip/Ribbon/Wire	Standard:	ASTM B206, DIN 17664, EN 12163
Advantage:	Good Price	Ip Address:	127.0.0.1
Feature:	Good Corrosion Protection	Model No:	TC Wire Thermocouple Wire
Sample:	Availiable

Shape:	Strip/Ribbon/Wire
Standard:	ASTM B206, DIN 17664, EN 12163
Advantage:	Good Price
Ip Address:	127.0.0.1
Feature:	Good Corrosion Protection
Model No:	TC Wire Thermocouple Wire
Sample:	Availiable

Description

Type K N E T C Thermocouple Bare Wire for Extension Cable

Tankii Thermocouple Wire Type K/N/E/T/C Thermocouple Bare Wire for Extension Cable

Product Specifications

Attribute	Value
Shape	Strip/Ribbon/Wire
Standard	ASTM B206, DIN 17664, EN 12163
Feature	Good Corrosion Protection
Model No	TC wire thermocouple wire
Sample	Available

Thermocouple Extension & Compensation Wire

There are multiple types and grades of thermocouple wire. Each type has a specific combination of metal alloys that defines its characteristics. Thermocouple grade wire is used to manufacture thermocouple probes, normally for the junction and inside the stem sheath.

Thermocouple Types

Type K: Most commonly used with operating range from -200°C to +1260°C. Offers better oxidation resistance (except vs Type N). Not recommended for sulphurous atmospheres without protection.
Type N: Provides longer life, better high temperature exposure, and improved EMF drift reliability.
Type E: Highest EMF output per degree among standard thermocouples.
Type J: Cost-effective with high EMF output. Suitable for oxidizing conditions up to 760°C.
Type T: Suitable for oxidizing, reducing inert atmosphere or vacuum applications.

Wire Composition

Code	Positive Leg	Negative Leg
N	Ni-cr-si (NP)	Ni-si-magnesium (NN)
K	Ni-Cr (KP)	Ni-Al(Si) (KN)
E	Ni-Cr (EP)	Cu-Ni (constantan) (EN)
J	Iron (JP)	Cu-Ni (constantan) (JN)
T	Copper (TP)	Cu-Ni (constantan) (TN)

International Standards Compliance

Complies with ASTM E 230, ANSI MC 96.1, IEC 584-1/2/3, DIN EN 60584 -1/2, BS 4937.1041, NF EN 60584 -1/2, JIS C 1602, and GOST 3044 standards.

Construction Details

Thermocouple extension wire connects thermocouples to display/control meters to minimize inaccuracy from temperature changes at connections.

Conductor: Original thermocouple alloy material in solid or stranded wire
Insulation Options: Fiberglass (0-300°C), PVC (0-105°C), Teflon (0-350°C), Silicone rubber (0-180°C)
Jacket Materials: Fiberglass, PVC, silicone rubber
Galvanized Layer Options: Stainless steel, tinned brass

Company Commitment

We continuously modernize our alloy sales operations through facility upgrades and employee training. Our growing global trade network is built on reputation and trust, promoting international economic and technical exchanges. We look forward to establishing long-term partnerships and creating mutual success.
