Tankii E Type Chromel Constantan Bare Thermocouple Wire

Name: Tankii E Type Chromel Constantan Bare Thermocouple Wire
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: Tankii E
Price: 25 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: TANKII

Model Number: Tankii E

Payment & Shipping Terms

Minimum Order Quantity: 15KG

Price: 25USD/KG

Packaging Details: Carton+wooden crate

Delivery Time: 15DAYS

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 10TON/MONTH

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                    E type Thermocouple Wire, Bare Thermocouple Wire, Chromel Constantan Thermocouple Wire


Description

Tankii E Type Chromel Constantan Bare Thermocouple Wire

Basic Info.

Model NO.

Application

Thermocouple sensor

Conductor Material

Chromel Constantan

Sheath Material

bare

Insulation Material

Bare

Material Shape

Round Wire

Range of Application

Temperature Measurement

Certification

ISO9001, CE

Brand

Tankii

Conductor

K, J, T, E, N,

Dia

0.05~12mmm

Surface

Bright/ oxidized

Grade

I/II

Item

Bare Thermocouple Wire type E NiCr via constantan

Chromel

Constantan

MOQ

10kg

Transport Package

Roll with Plastic Film Wrapped and Carton Package

Specification

0.3/0.5/0.8/1.0/1.2/1.6/2.0/2.5/3.2mm

Trademark

Tankii

Origin

China

HS Code

75052200

Production Capacity

1000ton/Year

Product Description

Product Desprition

Bare Thermocouple Wire type E NiCr via constantan
What's E type thermocouple wire ?
NiCr- CuNi thermocouple (type E) is also named NiCr-Constantan thermocouple. It has a stronger signal & higher accuracy than the Type K or Type J at moderate temperature ranges of 1,000F and lower. The type E is also more stable than the type K, which adds to its accuracy.

Type E thermocouple has the largest EMF output and highest sensitivity, so it is ideal for measuring small temperature change. It also has good stability in the low temperature range up to 300ºC, and good property of anti-corrosion in humidity atmosphere. It is recommended for oxidizing or inert atmospheres, but cannot be used directly in reducing atmosphere and atmosphere with sulphur gases.

Detailed Parameter of thermocouple wire

Chemical Composition
Conductor Name	Polarity	Code	Nominal Chemical Composition /%
Conductor Name	Polarity	Code	Ni	Cr	Cu
NiCr	Positive	EP	90	10	--
Cu-Ni(Constantan)	Negative	EN	45	--	55

Working Temperature Range
Diameter/mm	Long time Working temperature /ºC	Short period Working temperature /ºC
0.3, 0.5	350	450
0.8, 1.0, 1.2	450	550
1.6, 2.0	550	650
2.5	650	750
3.2	750	900

Packaging Details: 500m/1000m per roll with plastic film wrapped and carton package. As the order quantity and customer requirement.
Delivery Detail: By sea/ air. About 7 days, as the order quantity of thermocouple wire.
Tankii E Type Chromel Constantan Bare Thermocouple Wire 0

Tankii E Type Chromel Constantan Bare Thermocouple Wire 0

Tankii E Type Chromel Constantan Bare Thermocouple Wire 1

Tankii E Type Chromel Constantan Bare Thermocouple Wire 2
