C14415 Tsn0.12 Cusn0.15 C14420 Copper Strip Foil for Heat Exchanger Fin

Name: C14415 Tsn0.12 Cusn0.15 C14420 Copper Strip Foil for Heat Exchanger Fin
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: C14415
Price: 35.00 USD
Availability: InStock

Product Details

Place of Origin: Shanghai, China

Brand Name: TANKII

Certification: ISO9001 SGS

Model Number: C14415

Payment & Shipping Terms

Minimum Order Quantity: 100 KG

Price: negotiable

Packaging Details: Wooned Case

Delivery Time: 7-20 days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 500 Tons per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              C14415 Copper Strip Foil, C14420 Copper Strip Foil


Material:	Copper Tin Alloy	Grade:	C14415
Width:	1.0-600mm	Thickness:	0.02-2.5mm
Surface:	Bright	Origin:	Shanghai China
HS Code:	7409210000	Production Capacity:	500ton/Month

Material:	Copper Tin Alloy
Grade:	C14415
Width:	1.0-600mm
Thickness:	0.02-2.5mm
Surface:	Bright
Origin:	Shanghai China
HS Code:	7409210000
Production Capacity:	500ton/Month

Description

C14415 Tsn0.12 Cusn0.15 C14420 Copper Strip Foil for Heat Exchanger Fin

C14415 Tsn0.12 Cusn0.15 C14420 Copper Strip Foil for Heat Exchanger Fin

CHEMICAL COMPOSITION

	Sn%	Cu%
Nominal Composition		Bal.
Min	0.10
Max	0.15

PHYSICAL PROPERTIES

Density g/cm3	8.93
Conductivity at 20°C %IACS	83
Elastic Modulus GPa	120
Poisson's ratio	0.33
Thermal expansion coefficient 10-6/ K	17.3

MECHANICAL PROPERTIES

State	Yield strength	Tensile strength	Elongation	Hardness
	Mpa	MPa	A50%	HV
R300	≥250	300-370	≥4	85-110
R360	≥300	360-430	≥3	110-130
R420	≥350	420-490	≥2	120-150
R460	≥410	≥460	-	≥130

Bending performance

Bending thickness: ≤0.5 mm, bending width: 10 mm

State	90° R/T		180° R/T
	GW	BW	GW	BW
R300	0	0	0.5	0.5
R360	0	0	1	1
R420	1	1	2	2.5
R460	1.5	2	2.5	4

Alloy System	designation	UNS	EN	JIS	GB (China)
Cu	TK11000	C11000	Cu-ETP	C1100	T2
CuCr/Zr	TK15100	C15100	CuZr0.1	C1510	TZr0.1
	TK18160	C18160	CuCr0.5Zr	—
	TK18150	C18150	CuCr1Zr	—	TCr1-0.15
CuCrSiTi	TK18070	C18070	CuCrSiTi	—	TCr0.3-0.2- 0.05
CuNiSnCrTi	TK18090	—	—	—
CuNiP	TK19000	C19000	CuNi1P	—
CuTi	TK19920	C19920	—	—	—
CuFe	TK19210	C19210	CuFe0.1P	C1921	TFe0.1
CuFe	TK19400	C19400	CuFe2P	C1940	TFe2.5
CuNiSi	TK19005	C19005	—	—	—
	TK19010	C19010	CuNiSi	—	—
	TK70260	C70260	CuNi2Si	C7026	BSi2-0.45
	TK70250	C70250	CuNi3SiMg	C7025	BSi3.2-0.7
	TK70250HS	C70250	CuNi4SiMg	C7025	—
CuNiCoSi	TK70318	C70318	CuNi3CoSi	—	—
Special Brass	TK42300	C42300	CuZn10Sn1NiSi	—	—
Special Brass	TK42500	C42500	CuSn3Zn9	—	HSn88-2
CuSn / Bronze	TK14415	C14415	CuSn0.15	—	TSn0.12
	TK51000	C51000	CuSn5	C5102	QSn5-0.2
	TK51100*	C51100	CuSn4	C5111	QSn4-0.3
	TK51900*	C51900	CuSn6	C5191	QSn6-0.2
	TK52100*	C52100	CuSn8	C5210	QSn8-0.3
	TK52400	C52400	CuSn10	C5241	QSn10-0.2
CuNiZn	TK77000	C77000	CuNi18Zn27	C7701	BZn18-26
CuNiZn	TK75200	C75200	CuNi18Zn20	C7521	BZn18-18
