|Material:||Pure Silver Wire||Purity:||9999 Min|
|Sample:||Accepted Small Order||Origin:||Shanghai, China|
|HS Code:||7106921000||Status:||Soft / Hard|
1.5mm Pure Silver Wire,
ASTM Pure Silver Wire,
Length 2000mm Pure Silver Wire
0.05-1.5mm High purity Ag 99.99% Pure Silver Wire for Jewelry
1. silver wire
2. Material Grade:Ag-1,AgCu55/AgNi9
3. Standard: ASTM BS JIS NF DIN GB
4. Diameter: 0.03-10mm
5. Length: up to 2000mm,or in coils
6. Process: cold drawn;
7. Surface: mill surface, polished surface
8. Temper: soft;half hard;
White shiny face-centered cubic structure metal, soft, ductility second only to gold, is an excellent conductor of heat and electricity; does not react with water and atmospheric oxygen, and turns black when exposed to ozone, hydrogen sulfide and sulfur ; It is inert to most acids and can quickly dissolve in dilute nitric acid and hot concentrated sulfuric acid. Hydrochloric acid can corrode the surface and dissolve in molten alkali hydroxide, peroxide alkali and alkali cyanide in the air or in the presence of oxygen; Most silver salts are sensitive to light and are insoluble in many acids.
1. standard Silver Coated Copper Wire:
JB/T 3135-2011 Silver coated annealed round copper wire.
ASTM B298-12 Standard Specification for Silver-Coated Soft or Annealed Copper Wire.
Silver Coating: uniform,continous,good adhension.
Surface Finish:The surface of silver coated copper wire is bright,continous and free from harmful defects such as silver grains,burr,mechanical damange.
Joints:One single strand wire each reel. No joints
Advantage:1.High conductivity; 2.High corrosion resistance;
Silver coated copper wire mainly used in High Frequency,wide frequency and high power signal transmission;Microelectronics and superfine electronic wire In these industries such as Electrical wire and cable,electronics,computer,medical treatment,communications,aerospace,military industry, silver coated copper wire has been used widely.
2. Specification of Ag-Al series Aluminum-Silver alloy wire:
Ag98Al2: 98%silver 2% aluminium
Ag95Al5: 95%silver 5% aluminium
Ag90Al10: 90%silver 10% aluminium
Ag5Al95: 5% sliver 95%aluminium
Ag2Al92: 2% sliver 98%aluminium
Packing:500g or 1kg per spool.
Features of silver Aluminum alloy wire
Excellent solderability, short wetting time
Uniform distrbution of rosin, good continuity
Low fume, free of odor and harmful valatile gases
Bright and tidy spool
Detailed Product Description
lead free solder wire, no clean solder wire. Our prodct is SGS certificated and passed RoHs.
advantage of silver Aluminum alloy wire
1. Even and bright soldering spot
2. favorable diffusion & welding performance
3. minimum spattering, small smoking & no pungent smell
4. no corrosion
5. lowest and clear flux residue
6. non-conductive, Good insulating properties
0.5mm~5mm (According to customer's requirements)
Application of silver Aluminum alloy wire
silver-aluminium alloy wire can be used for Anticorrosion industry such as the steel structure surface anticorrosion, the container, the bridge, the derrick, the storage tank, the electric power iron tower, Power Tower, the capacitor, metal stent, ductile cast iron pipes,transportation equipment,etc.
3. Pure Silver Alloy Wires, silver winding wire
|Material||Composition||Density g/cm3||Resistivity μΩ. cm||Hardness HV kg/mm3|
|Ag||more than99.5||more than10.49||lessthan1.6||30--70|
Specification of Pure Silver Wires
|Item Name||high purity Silver Wires for Coating 99.5% silver Wire|
|Shape||Wire, According to your request|
|Available size||φ0.025mm-10.0mm Customization is available|
|Certificates||ISO9001:2008, SGS, The third test report|
|Technics||Vacuum Melting, Patented thermo-mechanical process|
|Application||Widely used in coating processing industries
A: Solar Photovoltaic Application.
B: Electronic and Semiconductor Application.
C: Decoration and Coating Application. etc.
Feature of silver alloy wire:
|category||Pure silver wire|
|when drawing 1% yield strength||110-150|
|package detail||spool 200mm*250mm*200mm|
