Product Details
Place of Origin: Shanghai,China
Brand Name: TANKII
Certification: BS,ASTM,AISI,CTI
Model Number: 0Cr25Al5
Payment & Shipping Terms
Minimum Order Quantity: 100KG
Packaging Details: on spool,paper box,wooden case/pallet,in coil
Delivery Time: 30days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 600T per moth
Port: |
Shangahi,China |
Brand: |
Tankii |
Cr: |
23.0-26.0 |
Al: |
4.5-6.5 |
Re: |
Opportune |
Fe: |
Bal |
Maxcontinuous Operating Temperature(℃): |
1250 |
Resisitivity20℃(Ωmm2/m): |
1.42 |
Density(g/cm³): |
7.1 |
Thermal Conductivity At 20℃,w/(m·k): |
0.46 |
Linear Expansion Coefficient(x10﹣6/℃)20﹣1000℃: |
16 |
Approximate Melting Point(℃): |
1500 |
Tensile Strength(N/m㎡): |
630-780 |
Elongation%: |
>12 |
Section Variation Shrink Rate(%): |
60-75 |
Repeatedly Bend Frequency(F/R): |
>5 |
Hardness: |
200-260 |
Micrographic Structure: |
Ferrite |
Magnetic Property: |
Magnetic |
Fast Life(h/℃): |
≧80/1300 |
MOQ: |
100kg |
Port: |
Shangahi,China |
Brand: |
Tankii |
Cr: |
23.0-26.0 |
Al: |
4.5-6.5 |
Re: |
Opportune |
Fe: |
Bal |
Maxcontinuous Operating Temperature(℃): |
1250 |
Resisitivity20℃(Ωmm2/m): |
1.42 |
Density(g/cm³): |
7.1 |
Thermal Conductivity At 20℃,w/(m·k): |
0.46 |
Linear Expansion Coefficient(x10﹣6/℃)20﹣1000℃: |
16 |
Approximate Melting Point(℃): |
1500 |
Tensile Strength(N/m㎡): |
630-780 |
Elongation%: |
>12 |
Section Variation Shrink Rate(%): |
60-75 |
Repeatedly Bend Frequency(F/R): |
>5 |
Hardness: |
200-260 |
Micrographic Structure: |
Ferrite |
Magnetic Property: |
Magnetic |
Fast Life(h/℃): |
≧80/1300 |
MOQ: |
100kg |
FeCrAl Alloy is high resistance and electrical heating alloy.FeCrAl alloy can reach process temperatures of 2192 to 2282℉,corresponding to a resistance temperature of 2372℉.
In order to improve anti-oxidation ability and increase working life,we usually put addition of rare earths in the alloy,such as La+Ce,Yttrium,Hafnium,Zirconium,etc.
It is normally used in electrial furnace,glass top hobs,quartz tube heaters,resistors,catalytic converter,heating elements and etc.
Model No. | 0Cr25Al5 |
condtion | new |
feature | good form stability |
surface treatment | bright oxidation |
treatment | hot rolling or annealing |
dimension | specification |
color | silvery white |
MOQ | 100KG |
