Product Details
Place of Origin: Shanghai, China
Brand Name: TANKII
Certification: ISO9001 SGS
Model Number: SUS 304
Payment & Shipping Terms
Minimum Order Quantity: 100 KG
Price: negotiable
Packaging Details: Spool + Carton + Wooned Case
Delivery Time: 7-20 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 Tons per month
Name: |
SUS 304 |
Gr.: |
200,300,400 Series |
Dia.: |
0.018-0.15mm |
Sample: |
Accepted Small Order |
Surface: |
Bright Surface |
Heat Treatment: |
Annealing |
HS Code: |
7223000 |
Production Capacity: |
500 Tons/Month |
Standard: |
GB/AISI |
Weldability: |
Good |
Purity: |
8-11%Ni, 18-20% Cr |
Name: |
SUS 304 |
Gr.: |
200,300,400 Series |
Dia.: |
0.018-0.15mm |
Sample: |
Accepted Small Order |
Surface: |
Bright Surface |
Heat Treatment: |
Annealing |
HS Code: |
7223000 |
Production Capacity: |
500 Tons/Month |
Standard: |
GB/AISI |
Weldability: |
Good |
Purity: |
8-11%Ni, 18-20% Cr |
SS 304 fine wire refers to thin wire made from stainless steel grade 304. This type of wire is commonly used in a variety of applications where strength, durability, and corrosion resistance are important.
Fine wire made from SS 304 is typically used in applications that require a high degree of precision and tight tolerances, such as medical devices, electronics, and automotive components. It can also be used in applications where the wire is exposed to harsh environments, such as outdoor structures, marine equipment, and chemical processing.
SS 304 fine wire is typically available in a range of diameters, from very thin (less than 0.001 inches) to thicker gauges (up to 0.060 inches). It can be supplied in various forms, such as spools, coils, or straight lengths, depending on the application requirements.
One of the key advantages of SS 304 fine wire is its corrosion resistance, which is essential in applications where the wire is exposed to harsh conditions. Additionally, this type of wire is known for its high tensile strength and good ductility, which makes it easy to work with during fabrication.
| Stainless steel wire brand and chemical component list | ||||||||||||
| country | SS type | Chemical component | ||||||||||
| C(Max) | Si(Max) | Mn(Max) | P(Max) | S(Max) | Cr | Ni | Mo | N | Cu | Ti | ||
| USA | 304 | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 18.00-20.00 | 8.00-11.00 | ||||
| CN | 0Cr18Ni9 | 0.07 | 1.00 | 2.00 | 0.035 | 0.030 | 17.00-19.00 | 8.00-11.00 | ||||
| EU | 1.4301 | 0.07 | 1.00 | 2.00 | 0.040 | 0.015 | 17.00-19.50 | 8.00-10.50 | <=0.11 | |||
| USA | 304L | 0.035 | 1.00 | 2.00 | 0.045 | 0.030 | 18.00-20.00 | 8.00-12.00 | ||||
| CN | 00Cr19Ni10 | 0.03 | 1.00 | 2.00 | 0.035 | 0.030 | 18.00-20.00 | 8.00-12.00 | <=0.11 | |||
| EU | 1.4306 | 0.03 | 1.00 | 2.00 | 0.040 | 0.015 | 18.00-20.00 | 10.00-12.00 | ||||
| USA | 304H | 0.04-0.10 | 1.00 | 2.00 | 0.045 | 0.030 | 18.00-20.00 | 8.00-11.00 | ||||
| CN | 1Cr18Ni9 | 0.15 | 1.00 | 2.00 | 0.035 | 0.030 | 17.00-19.00 | 8.00-10.00 | ||||
| EU | 1.4301 | 0.07 | 1.00 | 2.00 | 0.040 | 0.015 | 17.00-19.50 | 8.00-10.50 | <=0.11 | |||
| USA | 316 | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 16.00-18.00 | 10.0-14.00 | 2.00-3.00 | |||
| CN | Ocr17Ni12Mo2 | 0.08 | 1.00 | 2.00 | 0.035 | 0.030 | 16.00-18.00 | 10.0-14.00 | 2.00-3.00 | |||
| EU | 1.4401 | 0.07 | 1.00 | 2.00 | 0.040 | 0.015 | 16.50-18.50 | 10.00-13.00 | 2.00-2.50 | <=0.11 | ||
| USA | 316L | 0.035 | 1.00 | 2.00 | 0.045 | 0.030 | 16.00-18.00 | 10.00-14.00 | 2.00-3.00 | |||
| CN | 00Cr17Ni14Mo2 | 0.3 | 1.00 | 2.00 | 0.035 | 0.030 | 16.00-18.00 | 12.00-15.00 | 2.00-3.00 | |||
| EU | 1.4404 | 0.3 | 1.00 | 2.00 | 0.040 | 0.015 | 16.50-18.50 | 10.00-13.00 | 2.00-2.50 | <=0.11 | ||
| USA | 321 | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 17.00-19.00 | 9.00-12.00 | 5*(C+N)-0.70 | |||
| CN | 0Cr18Ni10Tu | 0.08 | 1.00 | 2.00 | 0.035 | 0.030 | 17.00-19.00 | 9.00-12.00 | >5*C% | |||
| EU | 1.4541 | 0.08 | 1.00 | 2.00 | 0.040 | 0.015 | 17.00-19.00 | 9.00-12.00 | 5*C-0.70 | |||
| USA | 310S | 0.08 | 1.00 | 2.00 | 0.045 | 0.030 | 24.00-26.00 | 19.00-22.00 | ||||
| CN | 0Cr25Ni20 | 0.08 | 1.00 | 2.00 | 0.035 | 0.030 | 24.00-26.00 | 19.00-22.00 | ||||
SS 304 fine wire is used in a variety of applications where strength, durability, and corrosion resistance are required. Here are some common applications for SS 304 fine wire:
1. Medical devices: SS 304 fine wire is commonly used in medical devices, such as catheters, sutures, and stents, due to its biocompatibility, corrosion resistance, and strength.
2. Filtration: SS 304 fine wire is used in the production of filters, sieves, and screens due to its corrosion resistance and ability to withstand high temperatures and pressures.
3. Jewelry: SS 304 fine wire is also used to make jewelry, particularly for people with allergies to other metals. It is popular for its durability and resistance to tarnishing.
4. Springs: SS 304 fine wire is commonly used to make springs that require high corrosion resistance, such as those used in marine environments or chemical processing.
5. Textiles: SS 304 fine wire is used in the production of textiles, such as mesh fabrics and woven wire cloth, due to its strength, durability, and corrosion resistance.
6. Electronics: SS 304 fine wire is used in various electronic components, including heating elements, due to its high electrical conductivity and resistance to corrosion.
7. Automotive: SS 304 fine wire is also used in automotive applications, such as in the production of exhaust systems, due to its high temperature resistance and corrosion resistance.
