High Temperature Metal Alloys GH3625 Inconel 625 for Paper Industry / Sulfuric Acid Condenser

High Temperature Metal Alloys GH3625 Inconel 625 for Paper Industry / Sulfuric Acid Condenser

    • High Temperature Metal Alloys GH3625 Inconel 625 for Paper Industry / Sulfuric Acid Condenser
    • High Temperature Metal Alloys GH3625 Inconel 625 for Paper Industry / Sulfuric Acid Condenser
    • High Temperature Metal Alloys GH3625 Inconel 625 for Paper Industry / Sulfuric Acid Condenser
  • High Temperature Metal Alloys GH3625 Inconel 625 for Paper Industry / Sulfuric Acid Condenser

    Product Details:

    Place of Origin: China
    Brand Name: High Temp Alloy
    Certification: ISO 9001 and RoHS
    Model Number: GH3625 / Inconel 625 / UNS N06625

    Payment & Shipping Terms:

    Minimum Order Quantity: 50KG
    Price: USD 20~50$/ KG
    Packaging Details: Wooden cases, pallet.
    Delivery Time: 25~30 days
    Payment Terms: T/T, Western Union, L/C, Paypal
    Supply Ability: 30000KG per month
    Contact Now
    Detailed Product Description
    Shape: Strip, Sheet, Wire, Bar Condition: Bright/ Oxidized; Soft/ Hard
    Color: Silver, Dark Feature: Corrosion Resistance
    Material: Ni-Cr-Mo-Nb Applications: In Nitrate, Sulfuric, Phosphoric Acid

    High Temperature Metal Alloys GH3625 Inconel 625 for Paper Industry / Sulfuric Acid Condenser





    This alloy has the following features

    1. A variety of corrosive media oxidative and reductive environment have very good corrosion resistance
    2. Excellent resistance to corrosion and crevice corrosion points, and no cause due to chloride stress corrosion cracking
    3. Excellent corrosion resistance to inorganic acids, such as nitric acid, phosphoric acid, sulfuric acid, hydrochloric acid and a mixed acid of sulfuric acid and hydrochloric acid, etc.
    4. Excellent resistance to inorganic acid mixed solution capabilities corrosion
    5. Temperature of 40 ℃, at various concentrations of hydrochloric acid solution can exhibit excellent corrosion resistance
    6. Good workability and weldability, no weld cracking susceptibility
    7. Having a wall temperature of -196 ~ 450 ℃ in a pressure vessel for manufacturing certification
    8. By the American Association of Corrosion Engineers NACE standard certification (MR-01-75) meet the highest standards of grade VII of sour gas environments

    Inconel 625 Application field have

    1. Organic Chemistry Process Technology of chloride-containing components, particularly in the case of using an acid chloride catalyst
    2. For the manufacture of pulp and paper industry and bleaching digester tank
    3. Flue gas desulphurization absorber system, another heater flue gas inlet baffle, fan (wet), stirrer, baffle and flue
    4. Applied to the acidic environment for the manufacture of gas equipment and components
    5. Acetic acid and acetic anhydride generator
    6. Sulfuric acid condenser



    Physical properties



    >Density (g/cm3): 8.4

    >Melting point (℃): 1290~1350



    Chemical composition(%)





    Grade

    C

    Nb

    Si

    Ti

    Mn

    Al

    P

    S

    Ni

    Cr

    Mo

    Fe

    GH3625

    ≤0.1

    3.15~4.15

    ≤0.5

    ≤0.4

    ≤ 0.5

    ≤0.4

    ≤0.015

    ≤0.015

    58

    20~23

    8~10

    ≤5



    High Temperature Metal Alloys GH3625 Inconel 625 for Paper Industry / Sulfuric Acid Condenser



    Mechanical properties







    Yield Strength  RP0.2N/mm2

    Tensile Strength

    Rm N/mm2

    Elongation, %

    Hardness, HB

    GH3625

    345

    760

    30

    ≤220









    Specifications



    Grade

    GH3625

    Size

    Ф 0.1~20mm

    MOQ

    50 kgs

    Condition

    Soft/ Hard; Bright/ Oxidized
