Nicr8020 Grade Corrosion Resistant Nicr Alloy For Cartridge Elements

Nicr8020 Grade Corrosion Resistant Nicr Alloy For Cartridge Elements

  • Nicr8020 Grade Corrosion Resistant Nicr Alloy For Cartridge Elements
  • Nicr8020 Grade Corrosion Resistant Nicr Alloy For Cartridge Elements
  • Nicr8020 Grade Corrosion Resistant Nicr Alloy For Cartridge Elements
Nicr8020 Grade Corrosion Resistant Nicr Alloy For Cartridge Elements
Product Details:
Place of Origin: China Mainland
Brand Name: Tankii
Certification: ISO9001,SGS
Model Number: NCHW - 1 (NICr8020)
Payment & Shipping Terms:
Minimum Order Quantity: 20kg
Packaging Details: Standard exoprt package
Delivery Time: About 10-15 days after getting the payment
Payment Terms: T/T, Paypal, Western Union, MoneyGram,
Supply Ability: 1000Ton per year
Contact Now
Detailed Product Description
Surface: Bright Diameter: 0.04mm~7.0mm
Leading Time: 5~20 Days As Per The Order Qty Item: Nicr AA / Resistohm 80 / Stablohm 650 Strip Used For Dymamic Braking Resistors
Ribbons:: 0.05*0.2-2.0*6.0mm Grade: NiCr8020
High Light:

Corrosion Resistant Nicr Alloy

,

Cartridge Elements Nicr Alloy

,

Nicr8020 Grade Nicr Alloy

Reliable Quality Nicr8020 Corrosion-Resistant Mesh for Cartridge Elements


Nickel-chromium alloy with high and stable resistance, corrosion resistance, surface oxidation resistance, excellent coil- forming ability.it is an ideal material,it has good ductility,workability and weldability under high temperature and seismic strength.


Common Name:Ni80Cr20,Nikrothal 8,MWS-650,NiCrA,Tophet A,HAI-NiCr 80,Chromel A,Alloy A,Alloy 650,N8,Resistohm 80, Stablohm 650,Nichorme V,Nikrothal 80.

NiCr series: Cr20Ni80, Cr30Ni70, Cr15Ni60, Cr20Ni35, Cr20Ni30.



Normal composition%

C P S Mn Si Cr Ni Al Fe Other
Max
0.03 0.02 0.015 0.60 0.75~1.60 20.0~23.0 Bal. Max 0.50 Max 1.0 -

Typical Mechanical properties(1.0mm)
Yield strength Tensile Strength Elongation
Mpa Mpa %
420 810 30

Typical Physical properties
Density (g/cm3) 8.4
Electrical resistivity at 20ºC(Om*mm2/m) 1.09
Conductivity coefficient at 20ºC (WmK) 15
Coefficient of thermal expansion
Temperature Coefficient of Thermal Expansion x10-6/ºC
20 ºC- 1000ºC 18
Specific heat capacity
Temperature 20ºC
J/gK 0.46
Melting point (ºC) 1400
Max continuous operating temperature in air (ºC) 1200
Magnetic properties non-magnetic
Temperature Factors Of Electrical Resistivity
20ºC 100ºC 200ºC 300ºC 400ºC 600ºC
1 1.006 1.012 1.018 1.025 1.018
700ºC 800ºC 900ºC 1000ºC 1100ºC 1300ºC
1.01 1.008 1.01 1.014 1.021 -

Style of supply
Alloys Name Type Dimension
OhmAlloy109W Wire D=0.03mm~8mm
OhmAlloy109R Ribbon W=0.4~40mm T=0.03~2.9mm
OhmAlloy109S Strip W=8~250mm T=0.1~3.0mm
OhmAlloy109F Foil W=6~120mm T=0.003~0.1mm
OhmAlloy109B Bar Dia=8~100mm L=50~1000mm



1. Size dimension range:

Wire: 0.01-10mm
Ribbons: 0.05*0.2-2.0*6.0mm
Strip: 0.05*5.0-5.0*250mm
Bar:10-50mm

Key Features of nichrome products:

  1. Nichrome 80 is a proven electrical resistance heating material
  2. Produces adherent chromium oxide layer to prevent oxidation
  3. Highly durable and corrosion resistant
  4. Ideal for use in frequent temperature switching application


2 Products and services
1> ROHS cerfication;
2.> Small orders are accepted;
3.> Factory direct sale;
4.> Timely delivery;
5> Samples are available;
3 Features
1>. Good oxidation resistance;
2> . Low embrittlement at high temperature;
3.> Good plasticity(easier to give them a shape);
4> . Nice performance and processing;
4 Applications
1> . In metal sheathed tubular elements used in grills;
2> . Toaster ovens;
3.> Storage heaters;
4.> As suspended coils in air heaters;
5.> Used in clothes dryers, fan heaters, hand dryers;
6> . Industrial hot wire foam cutters.

They are used for the manufacture of electric resistances for appliances (insulated elements type tubular resistances or for example opened elements on micanit plate) or for application of industrial furnaces.
In addition of a relatively high specific resistance, Ni-Cr alloys join all the necessary properties for good performances in use of furnaces: Resistance to oxidation (they are not sensitive to aggressions of humid air).

Nicr8020 Grade Corrosion Resistant Nicr Alloy For Cartridge Elements 0
Nicr8020 Grade Corrosion Resistant Nicr Alloy For Cartridge Elements 1
Nicr8020 Grade Corrosion Resistant Nicr Alloy For Cartridge Elements 2
Nicr8020 Grade Corrosion Resistant Nicr Alloy For Cartridge Elements 3
Nicr8020 Grade Corrosion Resistant Nicr Alloy For Cartridge Elements 4

Mine trolley brake resistor:
Nicr8020 Grade Corrosion Resistant Nicr Alloy For Cartridge Elements 5
