Product Details
Place of Origin: Shanghai
Brand Name: Tankii
Certification: DIN, ASTM, JIS
Model Number: FeCrAl Alloy
Payment & Shipping Terms
Minimum Order Quantity: 20kg
Packaging Details: spool ,coil, or as clients' requirement
Delivery Time: 25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1000T/month
Application: |
Heating |
Shape: |
Round Wire |
Material: |
FeCrAl |
Dimensions: |
Specifications |
Surface: |
Bright |
Color: |
Silvery White |
Standard: |
ASTM/GB |
Feature: |
Good Form Stability |
Condition: |
Soft |
Treatment: |
Hot Rolling |
Application: |
Heating |
Shape: |
Round Wire |
Material: |
FeCrAl |
Dimensions: |
Specifications |
Surface: |
Bright |
Color: |
Silvery White |
Standard: |
ASTM/GB |
Feature: |
Good Form Stability |
Condition: |
Soft |
Treatment: |
Hot Rolling |
FeCrAl Alloy Resistance Heating wire
About Resistance Heating Wire:
We are the greatest professional manufacturer of resistance heating alloy in China, specializing in Ferro-Chrome (Fe-Cr-AL) wire, Nickel-Chrome (Nichrome) wire, Copper Nickel (Constantan) wire, Stainless steel wire and related products in alloys tailored to meet specific customer requirements
Size details
| Product name | Size range |
| Cold drawing wire | Diameter 0.03-7.5mm |
| Hot-rolled wire rod | Diameter 8.0-12mm |
| Ribbon | Thickness 0.05-0.35mm |
| Width 0.5.0-3.5mm | |
| Cold rolled strip | Thickness 0.5-2.5mm |
| Width 5.0-40mm | |
| hot rolled strip | Thickness 4-6mm |
| Width 15-40mm |
basic parameters:
| basic parameters | Kanthall APMTM | Kanthall | ||
| A-1 | AF | D | ||
| The highestcontinuous working temperature | 1425 | 1400 | 1300 | 1300 |
| The nominal chemical composition,% Cr | 22 | 22 | 22 | 22 |
| AI | 5.8 | 5.8 | 5.3 | 4.8 |
| Fe | ingredients | ingredients | ingredients | ingredients |
| Ni | - | - | - | - |
| The resistivity in 20ºC,Ωmm-2mm-1 | 1.45 | 1.45 | 1.39 | 1.35 |
| density,g/cm3 | 7.1 | 7.1 | 7.15 | 7.25 |
| Thermal expansion coefficientK-1 20-750ºC | 14*10-6 | 14*10-6 | 14*10-6 | 14*10-6 |
| 20-1000ºC | 15*10-6 | 15*10-6 | 15*10-6 | 15*10-6 |
| The thermal conductivity 20ºC,Wm-1K-1 | 13 | 13 | 13 | 13 |
| Specific heat capacity 20ºC,KJkg-1K-1 | 0.46 | 0.46 | 0.46 | 0.46 |
| Melting pointºC | 1500 | 1500 | 1500 | 1500 |
| Probably mechanical characteristics | ||||
| Tensile strength,N mm-2 | 680 | 680 | 680 | 650 |
| The yield strength,N mm-2 | 470 | 475 | 475 | 450 |
| Hardness,Hv | 230 | 230 | 230 | 230 |
| Breaking elongation,% | 20 | 18 | 18 | 18 |
| 900ºCTensile strength,N mm-2 | 40 | 34 | 37 | 34 |
| Creep strength 800ºC | 11 | 6 | 8 | 6 |
| 1000ºC | 3.4 | 1 | 1.5 | 1 |
| Magnetic | magnetic(In the temperature600ºC) | |||
| Emissivity, the oxidation conditions | 0.7 | 0.7 | 0.7 | 0.7 |
Specification:
| Alloy Type | Diameter | Resistivity | Tensile | Elongation (%) |
Bending | Max.Continuous | Working Life |
| (mm) | (μΩm)(20°C) | Strength | Times | Service | (hours) | ||
| (N/mm²) | Temperature(°C) | ||||||
| Cr20Ni80 | <0.50 | 1.09±0.05 | 850-950 | >20 | >9 | 1200 | >20000 |
| 0.50-3.0 | 1.13±0.05 | 850-950 | >20 | >9 | 1200 | >20000 | |
| >3.0 | 1.14±0.05 | 850-950 | >20 | >9 | 1200 | >20000 | |
| Cr30Ni70 | <0.50 | 1.18±0.05 | 850-950 | >20 | >9 | 1250 | >20000 |
| ≥0.50 | 1.20±0.05 | 850-950 | >20 | >9 | 1250 | >20000 | |
| Cr15Ni60 | <0.50 | 1.12±0.05 | 850-950 | >20 | >9 | 1125 | >20000 |
| ≥0.50 | 1.15±0.05 | 850-950 | >20 | >9 | 1125 | >20000 | |
| Cr20Ni35 | <0.50 | 1.04±0.05 | 850-950 | >20 | >9 | 1100 | >18000 |
| ≥0.50 | 1.06±0.05 | 850-950 | >20 | >9 | 1100 | >18000 | |
| 1Cr13Al4 | 0.03-12.0 | 1.25±0.08 | 588-735 | >16 | >6 | 950 | >10000 |
| 0Cr15Al5 | 1.25±0.08 | 588-735 | >16 | >6 | 1000 | >10000 | |
| 0Cr25Al5 | 1.42±0.07 | 634-784 | >12 | >5 | 1300 | >8000 | |
| 0Cr23Al5 | 1.35±0.06 | 634-784 | >12 | >5 | 1250 | >8000 | |
| 0Cr21Al6 | 1.42±0.07 | 634-784 | >12 | >5 | 1300 | >8000 | |
| 1Cr20Al3 | 1.23±0.06 | 634-784 | >12 | >5 | 1100 | >8000 | |
| 0Cr21Al6Nb | 1.45±0.07 | 634-784 | >12 | >5 | 1350 | >8000 | |
| 0Cr27Al7Mo2 | 0.03-12.0 | 1.53±0.07 | 686-784 | >12 | >5 | 1400 | >8000 |
Advantage:
Nickelchromium alloy with high and stable resistance, corrosion resistance, surface oxidation resistance is good, a better under high temperature and seismic strength, good ductility, good workability and weldability
Shanghai Tankii Alloy Material Co., Ltd. Focus on the production of resistance alloy(nichrome Alloy, FeCrAl Alloy, copper nickel alloy, thermocouple wire, precision alloy and thermal spray alloy in the form of wire, sheet, tape, strip, rod and plate. We've already got ISO9001 quality system certificate and approval of ISO14001 environmental protection system. We own a complete set of advanced production flow of refining, cold reduction, drawing and heat treating etc. We also proudly have independent R&D capacity.
Shanghai Tankii Alloy Material Co., Ltd has accumulated lots of experiences over 35 years in this field. During these years, more than 60 management elites and high science and technology talents were employed. They participated in every walk of the company life, which make our company keep blooming and invincible in the competitive market. Based on the principle of "first quality, sincere service", our managing ideology is pursuing technology innovation and creating the top brand in the alloy field. We persist in Quality - the foundation of the survival. It is our forever ideology to serve you with full heart and soul. We committed to provide customers all over the world with high-quality, competitive products and perfect service.
Our products, such us nichrome alloy, precision alloy, thermocouple wire, fecral alloy, copper nickel alloy, thermal spray alloy have been exported to over 60 countries in the world. We are willing to establish strong and long-time partnership with our customers. Most complete range of products dedicated to Resistance, Thermocouple and Furnace manufacturers Quality with end to end production control Technical support and Customer Service.
