Product Details
Place of Origin: Shanghai, China
Brand Name: TANKII
Certification: SGS
Model Number: Inconel X750
Payment & Shipping Terms
Minimum Order Quantity: 100 KG
Price: Negotiable
Packaging Details: wooden case
Delivery Time: 7-12 work days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 Ton per month
Material: |
Ni-Cr-Ti-Nb-Fe-Al |
Standard: |
ASTM / GB |
OD: |
0.02-10mm |
Surface: |
Bright |
Shape: |
Rod, Bar,,tube,plate, Wire |
Density: |
8.28 G/cm3 |
Material: |
Ni-Cr-Ti-Nb-Fe-Al |
Standard: |
ASTM / GB |
OD: |
0.02-10mm |
Surface: |
Bright |
Shape: |
Rod, Bar,,tube,plate, Wire |
Density: |
8.28 G/cm3 |
Nickel Alloy Inconel X-750 (UNS N07750, Alloy X750, inconel X750) Round Bar / wire / plate
Chemical Composition
Grade | Ni% | Cr% | Nb% | Fe% | Al% | Ti% | C% | Mn% | Si% | Cu% | S% | Co% |
Inconel X750 | Max 70 | 14-17 | 0.7-1.2 | 5.0-9.0 | 0.4-1.0 | 2.25-2.75 | Max 0.08 | Max 1.00 | Max 0.50 | Max 0.5 | Max 0.01 | Max 1.0 |
Specifications
Grade | UNS | Werkstoff Nr. |
Inconel X750 | N07750 | 2.4669 |
Physical Properties
Grade | Density | Melting Point |
Inconel X750 | 8.28 g/cm3 | 1390°C-1420 °C |
Mechanical Properties
Inconel X750 | Tensile Strength | Yield Strength | Elongation | Brinell Hardness (HB) |
Solution Treatment | 1267 N/mm² | 868 N/mm² | 25% | ≤400 |
Our Production Standard
Bar | Forging | Pipe | Sheet/Strip | Wire | |
Standard | ASTM B637 | ASTM B637 | AMS 5582 | AMS 5542 AMS 5598 |
AMS 5698 AMS 5699 |
Size Range
Inconel X750 is available as wire, strip, sheet, rod and bar. In the wire form, this grade is covered by specification AMS 5698 for No.1 Temper and AMS 5699 for spring temper grade. No.1 Temper has a higher service temperature than Spring temper, but lower tensile strength.
