PFA Insulation Silver Copper Alloy Wire 1.5mm Tinned Copper Stranded Wire

PFA Insulation Silver Copper Alloy Wire 1.5mm Tinned Copper Stranded Wire

  • PFA Insulation Silver Copper Alloy Wire 1.5mm Tinned Copper Stranded Wire
  • PFA Insulation Silver Copper Alloy Wire 1.5mm Tinned Copper Stranded Wire
  • PFA Insulation Silver Copper Alloy Wire 1.5mm Tinned Copper Stranded Wire
PFA Insulation Silver Copper Alloy Wire 1.5mm Tinned Copper Stranded Wire
Product Details:
Place of Origin: Shanghai, China
Brand Name: TANKII
Certification: ISO9001 SGS
Model Number: Silver plated copper wire
Payment & Shipping Terms:
Minimum Order Quantity: 100 KG
Price: negotiable
Packaging Details: Spool + Carton + Wooned Case
Delivery Time: 7-20 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 Tons per month
Contact Now
Detailed Product Description
Material: Silver Plated Copper Wire Diameter: 0.05-1.5mm
Surface: Bright Sample: Accepted Small Order
Spool: DIN63 DIN80 DIN100 DIN125 Etc.
High Light:

PFA Insulation Silver Copper Alloy Wire

,

1.5mm Tinned Copper Stranded Wire

,

DIN63 Tinned Copper Stranded Wire

Applications:

Heating appliances, PTC thermistor, temperatures, Coating equipment, automotive interior cables, electronic appliances etc.

Technical Data:

  • Insulation: PFA
  • Conductor: Silver or Nickel Copper
  • Temperature: -65'C~+250'C
  • Voltage: 600V
  • Color: White-Blue-Red-Black-Brown-Yellow-Green-Transparent-Yellow/Green
Conductor Insulation Electrical Properties Packing
Sectional
Area mm²
Conductor
Construction
NO.XΦmm
Diameter
mm
Insulation
Thickness
mm
Outer
Diameter
mm
Max.Conductor
Resistance DC 20'C
Ω/km
M/coil
0.05 7x0.10 0.30 0.20 0.70 376.2 500
0.20 7x0.20 0.60 0.30 1.20 83.50 500
0.35 19x0.16 0.80 0.30 1.40 49.50 500
0.50 19x0.18 0.90 0.35 1.60 36.00 500
0.75 19x0.23 1.15 0.35 1.85 22.70 500
1.0 19x0.26 1.30 0.35 2.00 19.00 200
1.2 19x0.28 1.40 0.35 2.10 15.30 200
1.5 19x0.32 1.60 0.40 2.40 11.70 200
2.0 19x0.37 1.85 0.40 2.65 9.450 200
2.5 19x0.41 2.05 0.50 3.05 6.860 200
4.0 37x0.37 2.60 0.50 3.60 4.510 200
6.0 37x0.45 3.15 0.50 4.15 3.050 100
10.0 133x0.32 4.80 0.50 5.80 1.680 100
16.0 133x0.39 5.80 0.60 7.0 1.130 100
20 133/0.45 6.80 0.60 8.0 0.886 100
25 196/0.40 7.60 0.60 8.8 0.734 100
35 494/0.30 9.0 0.70 10.4 0.511 100
50 551/0.40 10.6 0.80 12.2 0.358 100
70 551/0.40 12.6 1.0 14.6 0.270 100
95 760/0.40 14.8 1.2 17.2 0.210 100



PFA Insulation Silver Copper Alloy Wire 1.5mm Tinned Copper Stranded Wire 0
