Product Details
Place of Origin: CHINA
Brand Name: TANKII
Certification: ISO9001
Model Number: NiCr6023
Payment & Shipping Terms
Minimum Order Quantity: 10kg
Packaging Details: Carton Box
Delivery Time: 2~5 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 5000Ton/Year
Material: |
Nickel 60%, Chromium 23% |
Surface: |
Bright |
Pakage: |
In Coil |
Material: |
Nickel 60%, Chromium 23% |
Surface: |
Bright |
Pakage: |
In Coil |
High Quality Nichrome Ribbon Nicr6023 for Electric Heating Elements
NC6023 Resistance Wire 0.3mm Used For Metal-Sheathed Tubular Elements
Nickel chromium alloy with iron resistance electrothermal high resistivity, surface body sexual well. At high
temperature and high intensity, and a good performance and processing may welding nature widely used
metallurgical, electrical, mechanical components and electrical manufacturing industries for doing heat
resistance material.
Typical applications include metal-sheathed tubular elements used in hot plates, grills, toaster ovens, storage heaters, etc
NiCr Type:Cr20Ni80,Cr15Ni60, Cr20Ni35, Cr20Ni30, Cr25Ni20 etc.Series electric flat belt, electric fire wire.
3.Product size:
Round wire dia.0.02-12mm;
flat strip thickness 0.03-5mm,flat strip width0.2-500mm.
NC6023 Resistance Wire 0.3mm Used For Metal-Sheathed Tubular Elements
| Chemical Composition | Nickel , Chrome |
| Condition | Bright/Acid white/Oxidied Color |
| Grade | Ni80Cr20, Ni70/30, Ni60Cr15, Ni60Cr23, Ni35Cr20Fe, Ni30Cr20 Ni80, Ni70,Ni60, Ni40, |
| Advantage | Nichrome's metallurgical structure confers them a very good plasticity when cold. |
| Characteristics | Stable performance; Anti-oxidation; Corrosion resistance; High temperature stability; Excellent coil-forming ability; Uniform and beautiful surface condition without spots. |
3. Chemical Composition of NiCr6015
| C | P | S | Mn | Si | Cr | Ni | Al | Fe | Other |
| Max | |||||||||
| 0.08 | 0.02 | 0.015 | 0.60 | 0.75~1.60 | 22.0~23.0 | 55.0~61.0 | Max 0.50 | Bal. | - |
4. Typical Mechanical properties of Nicr6015
| Yield strength | Tensile Strength | Elongation |
| Mpa | Mpa | % |
| 370 | 730 | 35 |
5.Temperature Factors Of Electrical Resistivity
| 20ºC | 100ºC | 200ºC | 300ºC | 400ºC | 500ºC | 600ºC |
| 1 | 1.011 | 1.024 | 1.038 | 1.052 | 1.064 | 1.069 |
| 700ºC | 800ºC | 900ºC | 1000ºC | 1100ºC | 1200ºC | 1300ºC |
| 1.073 | 1.078 | 1.088 | 1.095 | 1.109 | - | - |
1.4867 / NC6015 Resistance Wire 0.3mm Used For Metal-Sheathed Tubular Elements
Our Nichrome alloy are in the form of wire, ribbon, strip, coil.
Nichrome products sizes are:
Wire: 0.025mm-10mm
Ribbon: 0.05*0.2mm-2.0*6.0mm
Strip: 0.02*5.0mm-5.0*250mm
Bar: 10-100mm
Rohs Certified 1.4867 NiCr6015/NC6015 Resistance Wire 0.3mm Used Electronic Instruments
NiCr 80:20 - Industrial furnaces (upto 1200°C), electric cooking equipment, precision resistors.
NiCr 70:30 - Industrial furnaces (upto 1230°C) with alternating oxidizing/reducing atmosphere, precision resistors.
NiCr 60:15 - Industrial furnaces (upto 1100°C), electrically heated equipment, high-resistance and potentiometer resistors.
NiCr 40:20 - Domestic heating appliances (upto 1050°C), furnaces in carburising or semi-reducing atmosphere.
NiCr 30:20/ NiCr 20:25 - Industrial furnaces (upto 1050°C), heating elements of cooking equipment.
Application:
