Product Details
Place of Origin: Shanghai
Brand Name: Tankii
Certification: DIN, ASTM, JIS
Model Number: heating element
Payment & Shipping Terms
Minimum Order Quantity: 20kg
Packaging Details: spool ,coil, or as clients' requirement
Delivery Time: 25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1000T/month
Type: |
Infrared Heater |
Condition: |
New |
Weight: |
Based |
Power Source: |
Electric |
After-sales Service Provided: |
Video Technical Support |
Voltage: |
220v |
Warranty: |
1 Year |
Material: |
Alloy |
Application: |
Furnace Heating |
Diameter: |
Dia.3/6 |
Type: |
Infrared Heater |
Condition: |
New |
Weight: |
Based |
Power Source: |
Electric |
After-sales Service Provided: |
Video Technical Support |
Voltage: |
220v |
Warranty: |
1 Year |
Material: |
Alloy |
Application: |
Furnace Heating |
Diameter: |
Dia.3/6 |
Customize/OEM Defrosting Applied Tubular Heating Element
Description: Adopts high-quality stainless steel as the shell, high resistance alloy wire,magnesia powder as insulation,this product has good corrosion resistance, widely applied to defrosting of fridge, freezer, etc.
No.1 Silicone rubber seal
1, Stainless steel tube 2, Magnesia oxide powder
3, Resistance wire 4, Cold zone
5, Seal (Epoxy resin) 6, Connector
7, Silicone rubber seal 8, Lead
9, Hot melt hose No.2 Shrinkable tube seal
1, Stainless steel tube 2, Magnesia powder
3, Resistance wire 4, Cold zone
5, Seal (Epoxy resin) 6, Silicone plug
7, PE heat shrinkable tube 8, Connection terminal
9, PE heat shrinkable tube
Certification:
| No. | Certification | Voltage (V) | Power (W) | standard |
| 1 | VDE | 100-240 | 200-400 | DINEN60335-1(VDE0700-1):2012-10; EN 60335-12012 DINEN60335-1Ber.1(VDE 0700-1 Ber.1); 2014-04; EN60335-1:2012/AC:2014 EN 60335-1:2012/A11:2014 |
| 2 | UL | 100-240 | 100-300 | |
| 3 | Explosion-proof certification | 220 | 100-300 | GB3836.1-2010 GB3836.8-2003 |
Certification No. : VDE 40042722
UL SA44594
Ex-p CNEx19.4495X
Tests & Results:
| No. | Tests | Results |
| 1 | Overall length (mm) | According to your requirement |
| 2 | Resistance deviation (%) | ≤±7% |
| 3 | Insulation resistance at room temperature (mΩ) | >=1000 (soaking in water for 30 min) |
| 4 | Withstand voltage strength at room temperature | 1900V, 2S, no breakdown, no flashover |
| 5 | Leakage current (mA) | ≤0.5 (soaking in water for 30min) |
Shanghai Tankii Alloy Material Co., Ltd. Focus on the production of resistance alloy(nichrome Alloy, FeCrAl Alloy, copper nickel alloy, thermocouple wire, precision alloy and thermal spray alloy in the form of wire, sheet, tape, strip, rod and plate. We've already got ISO9001 quality system certificate and approval of ISO14001 environmental protection system. We own a complete set of advanced production flow of refining, cold reduction, drawing and heat treating etc. We also proudly have independent R&D capacity.
Shanghai Tankii Alloy Material Co., Ltd has accumulated lots of experiences over 35 years in this field. During these years, more than 60 management elites and high science and technology talents were employed. They participated in every walk of the company life, which make our company keep blooming and invincible in the competitive market. Based on the principle of "first quality, sincere service", our managing ideology is pursuing technology innovation and creating the top brand in the alloy field. We persist in Quality - the foundation of the survival. It is our forever ideology to serve you with full heart and soul. We committed to provide customers all over the world with high-quality, competitive products and perfect service.
Our products, such us nichrome alloy, precision alloy, thermocouple wire, fecral alloy, copper nickel alloy, thermal spray alloy have been exported to over 60 countries in the world. We are willing to establish strong and long-time partnership with our customers. Most complete range of products dedicated to Resistance, Thermocouple and Furnace manufacturers Quality with end to end production control Technical support and Customer Service.
