Red Color 0.1mm Enameled Winding Wire Polyester Insulation

Product Details

Place of Origin: China

Brand Name: Tankii

Certification: ISO9001

Model Number: N6 pure nickel wire

Payment & Shipping Terms

Minimum Order Quantity: 10 kg

Packaging Details: 500m/1000m per roll with plastic film wrapped and carton package. As the order quantity and customer requirement.

Delivery Time: 10-15 days after getting the payment

Payment Terms: T/T, Paypal, Western Union, MoneyGram,

Supply Ability: 1000Ton per year

Get Best Price
Contact Now
Specifications
Highlight:

0.1mm Enameled Winding Wire

,

Red Color Enameled Winding Wire

,

Polyester Insulation Enameled Winding Wire

Material:
Pure Nickel Wire
Surface:
Enamelled Color
Diameter:
0.025mm~1.0mm
Enamelled Type:
155 Centigrade C
MOQ:
5kg Per Size
Insulation Material:
Polyester
Leading Time:
20~30 Days
Payment:
100% Payment In Advance
Material:
Pure Nickel Wire
Surface:
Enamelled Color
Diameter:
0.025mm~1.0mm
Enamelled Type:
155 Centigrade C
MOQ:
5kg Per Size
Insulation Material:
Polyester
Leading Time:
20~30 Days
Payment:
100% Payment In Advance
Description
Red Color 0.1mm Enameled Winding Wire Polyester Insulation

Product Description:



Rohs Certified Ni200 Pure Nickel Wire 0.1mm With Red Color Enameled Insulation



Tankii alloy Nickel wire has high chemical stability and good corrosion resistance in many media.

Its standard electrode position is -0.25V, which is positive than iron and negative than copper.

Nickel exhibits good corrosion resistance in the absence of dissolved oxygen in dilute non-oxidized properties (e.g., HCU, H2SO4), especially in neutral and alkaline solutions.This is because nickel has the ability to passivate, forming a dense protective film on the surface, which prevents nickel from further oxidation.





Tankii enameled wires have been broadly used for standard resistors, automobile parts, winding resistors, etc. using the insulation processing best suited for these applications, taking full advantage of the distinctive features of enamel coating.


Furthermore, tankii will carry out enamel coating insulation of precious metal wire such as silver and platinum wire upon order.







Rohs Certified Ni200 Pure Nickel Wire 0.1mm With Red Color Enameled Insulation




Type of bare Alloy wire
The alloy we can do enamelled are Copper-nickel alloy wire,Constantan wire,Manganin wire. Kama Wire,NiCr Alloy wire,FeCrAl Alloy wire etc alloy wire
Size:
Round wire:0.025mm~3.0mm
Color of enamel insulation:Red,Green,Yellow,Black,Blue,Nature etc.
Ribbon Size:0.01mm*0.2mm~1.2mm*24mm
Moq:5kg each size



Enameled wire conductor:

Copper-nickel alloy wire, Constantan Wire,CuNi1~CuNi44
Ni-Cr Alloy wire NiCr35/20,NiCr70/30,NiCr60/15,NiCr80/20,NiCr90/10,NiCr AA,Karma.
Fe-Cr-Al Alloy wire Cr13Al4,Cr21Al4,Cr21Al6,Cr23Al5,Cr25Al5,
Cr21Al6Nb,Cr27Al7Mo2,
Cu-Ni-Mn Alloy wire CuMn12Ni2,CuMn12Ni4,Manganin
Stainless steel Wire
Silver Purity 9.99%
golden Wire
Any copper alloy and nickel alloy is available


Type of insulation

Insulation-enamelled Name Thermal LevelºC
(working time 2000h)
Code Name GB Code ANSI. TYPE
Polyurethane enamelled wire 130 UEW QA MW75C
Polyester enamelled wire 155 PEW QZ MW5C
Polyester-imide enamelled wire 180 EIW QZY MW30C
Polyester-imide and polyamide-imide double coated enameled wire 200 EIWH
(DFWF)
QZY/XY MW35C
Polyamide-imide enamelled wire 220 AIW QXY MW81C


Rohs Certified Ni200 Pure Nickel Wire 0.1mm With Red Color Enameled Insulation


Red Color 0.1mm Enameled Winding Wire Polyester Insulation 0
Application:

Applicable to radio, electric light source, mechanical manufacturing, chemical industry, pure nickel wire is an important structural material in vacuum electronic devices, can also be used as a guide wire lead in the bulb.


Rohs Certified Ni200 Pure Nickel Wire 0.1mm With Red Color Enameled Insulation



About us

Shanghai Tankii Alloy Material Co., Ltd. specialized in production of nickel alloy wire, copper alloy wire , resistance wire, thermocouple wire etc.

Our products have been exported to Europe, USA, India, Southest Asia, South America,etc.

Welcome to call me or email to me for more information on enamelled wire.
