Product Details
Place of Origin: China
Brand Name: Tankii
Certification: ISO9001
Model Number: N6 pure nickel wire
Payment & Shipping Terms
Minimum Order Quantity: 10 kg
Packaging Details: 500m/1000m per roll with plastic film wrapped and carton package. As the order quantity and customer requirement.
Delivery Time: 10-15 days after getting the payment
Payment Terms: T/T, Paypal, Western Union, MoneyGram,
Supply Ability: 1000Ton per year
Material: |
N6 Nickel |
Surface: |
Red , Green, Golden Etc |
Leading Time: |
10~35days |
Payment: |
50% Or 100% Payment In Advance |
Material: |
N6 Nickel |
Surface: |
Red , Green, Golden Etc |
Leading Time: |
10~35days |
Payment: |
50% Or 100% Payment In Advance |
Bare N6 0.025mm Enamel Insulated Wire Non Oxidized For Winding Resistors
Enamelled wire is the main raw material of motors, electrical appliances and household appliances. Especially in recent years, the power industry has achieved sustained and rapid growth. The rapid development of household appliances has brought a broader field to the application of enamelled wire, followed by higher requirements for enamelled wire
Tankii enameled wires have been broadly used for standard resistors, automobile parts, winding resistors, etc. using the insulation processing best suited for these applications, taking full advantage of the distinctive features of enamel coating.
Furthermore, we will carry out enamel coating insulation of precious metal wire such as silver and platinum wire upon order.
Main application fields:
Chemical and chemical engineering, generator anti-wet corrosion components (water inlet heater and steam pipe), pollution control equipment (waste gas sulfur removal equipment), etc.
Enamel Insulated Pure Nickel Wire N6 Wire 0.025mm With Red Color
Enameled wire conductor:
| Copper-nickel alloy wire, | Constantan Wire,CuNi1~CuNi44 | |
| Ni-Cr Alloy wire | NiCr35/20,NiCr70/30,NiCr60/15,NiCr80/20,NiCr90/10,NiCr AA,Karma. | |
| Fe-Cr-Al Alloy wire | Cr13Al4,Cr21Al4,Cr21Al6,Cr23Al5,Cr25Al5, Cr21Al6Nb,Cr27Al7Mo2, |
|
| Cu-Ni-Mn Alloy wire | CuMn12Ni2,CuMn12Ni4,Manganin | |
| Stainless steel Wire | ||
| Silver | Purity 9.99% | |
| golden Wire | ||
| Any copper alloy and nickel alloy is available | ||
Type of insulation
| Insulation-enamelled Name | Thermal LevelºC (working time 2000h) |
Code Name | GB Code | ANSI. TYPE |
| Polyurethane enamelled wire | 130 | UEW | QA | MW75C |
| Polyester enamelled wire | 155 | PEW | QZ | MW5C |
| Polyester-imide enamelled wire | 180 | EIW | QZY | MW30C |
| Polyester-imide and polyamide-imide double coated enameled wire | 200 | EIWH (DFWF) |
QZY/XY | MW35C |
| Polyamide-imide enamelled wire | 220 | AIW | QXY | MW81C |
