Alchrome 750 1Cr13Al4 1.0mm Thickness Fe Cr Al Alloy With 200mm Width

Product Details

Place of Origin: China Mainland

Brand Name: TANKII

Certification: ISO9001

Model Number: Alloy 750/ 1Cr13Al4

Payment & Shipping Terms

Minimum Order Quantity: Negotiation

Price: Negotiable

Packaging Details: On Spool, In Coil

Delivery Time: 2 days after getting the payment

Payment Terms: L/C, T/T, Western Union

Supply Ability: 1000 tons/year

Get Best Price
Contact Now
Specifications
Highlight:

1.0mm Thickness Fe Cr Al Alloy

,

Alchrome 750 Fe Cr Al Alloy

,

Weldable FeCrAl Alloy

Item:
Alchrome 750/ Alloy750/ Alferon902 1Cr13Al4 1.0 Mm Thickness Strip With 200mm Width
Stock Qty:
200kg
Melting Point:
1450 Degrees
Width:
Up To 1200mm
Item:
Alchrome 750/ Alloy750/ Alferon902 1Cr13Al4 1.0 Mm Thickness Strip With 200mm Width
Stock Qty:
200kg
Melting Point:
1450 Degrees
Width:
Up To 1200mm
Description
Alchrome 750 1Cr13Al4 1.0mm Thickness Fe Cr Al Alloy With 200mm Width



Alchrome 750/ Alloy750/ Alferon902 1Cr13Al4 1.0 mm Thickness Strip With 200mm Width



This alloy has the following characteristics:

13cr-4al has low aluminum and chromium content and high iron content. It has good oxidation resistance, thermal strength and high positive temperature coefficient below 800 ℃. At normal temperature, it has high plasticity, cold stamping and general welding performance. After annealing, the alloy has ferrite structure, and the structure is unstable during use. 475 ℃ is the brittle temperature zone. After long-term heating, the grain becomes coarser and coarser.



Shanghai Tankii havs stock of 1Cr13Al4 with  the following sizes for your choose:
1.2*90mm
1.0*250mm
1.5*130mm
1.0*90mm

The features of FeCrAl resistance electrothermal alloy:
1.  High resistivity
2. Good surface oxidation resistance
3. High strength at high temperature
4. Good processing performance and weldability

Typical Application:
1.Widely used in gold, household appliances,
2. Machinery manufacturing industry as heating elements
3. Electrical industry as resistance materials.



Alchrome 750/ Alloy750/ Alferon902 1Cr13Al4 1.0 Mm Thickness Strip With 200mm Width


3. Details of tankii  strips
Chemical Composition and Main Property of Fe-Cr-Al Resistance Alloy

Properties Grade

1Cr13Al4

0Cr25Al5

0Cr21Al6

0Cr23Al5

0Cr21Al4

0Cr21Al6Nb

0Cr27Al7Mo2

Main Chemical Composition
(%)


Cr

12.0-15.0

23.0-26.0

19.0-22.0

22.5-24.5

18.0-21.0

21.0-23.0

26.5-27.8

Al

4.0-6.0

4.5-6.5

5.0-7.0

4.2-5.0

3.0-4.2

5.0-7.0

6.0-7.0

Re

opportune

opportune

opportune

opportune

opportune

opportune

opportune

Fe

Bal.

Bal.

Bal.

Bal.

Bal.

Bal.

Bal.













Nb0.5

Mo1.8-2.2

Max Continuous Service Temperature(oC)

950

1250

1250

1250

1100

1350

1400

Resisivity 20oC (Ωmm2/m)

1.25
±0.08


1.42
±0.06


1.42
±0.07


1.35
±0.07


1.23
±0.07


1.45
±0.07


1.53
±0.07


Density(g/cm3)

7.4

7.1

7.16

7.25

7.35

7.1

7.1

Thermal Conductivity

52.7

46.1

63.2

60.2

46.9

46.1

45.2

(KJ/m@h@oC)

Coefficient of Thermal Expansion(α×10-6/oC)

15.4

16

14.7

15

13.5

16

16

Approximate Melting Point( oC)

1450

1500

1500

1500

1500

1510

1520

Tensile Strength(N/mm2)

580-680

630-780

630-780

630-780

600-700

650-800

680-830

Elongation(%)

>16

>12

>12

>12

>12

>12

>10

Section Variation

65-75

60-75

65-75

65-75

65-75

65-75

65-75

Shrink Rate (%)

Repeatedly Bend Frequency(F/R)

>5

>5

>5

>5

>5

>5

>5

Hardness (H.B.)

200-260

200-260

200-260

200-260

200-260

200-260

200-260

Continuous Service Time

no

≥80/1300

≥80/1300

≥80/1300

≥80/1250

≥50/1350

≥50/1350

Micrographic Structure

Ferrite

Ferrite

Ferrite

Ferrite

Ferrite

Ferrite

Ferrite

Magnetic Property

Magnetic

Magnetic

Magnetic

Magnetic

Magnetic

Magnetic

Magnetic

Alchrome 750/ Alloy750/ Alferon902 1Cr13Al4 1.0 Mm Thickness Strip With 200mm Width



1. Description
FECRAL Has been used extensively as heating elements in industrial furnaces and electrical kilns.
FECRAL Has less hot strength than Tophet alloys but much higher melting point.



2. Specification
1). Locomotive resistance strip:
Thickness:0.6mm-1.5mm
Width:60mm-90mm

Special width: up to 1200mm for 1Cr13Al4

2)Electric ceramic cooktop resistance strip:
Thickness:0.04mm-1.0mm
Width:5mm-12mm
Thickness&Width:(0.04mm-1.0mm)×12mm(above)


3). Low resistance ribbon:
Thickness&Width:(0.2mm-1.5mm)*5mm

4). Industrial furnace ribbon:
Thickness:1.5mm-3.0mm
Width:10mm-30mm



Alchrome 750 1Cr13Al4 1.0mm Thickness Fe Cr Al Alloy With 200mm Width 0




Application:



Cermet resistor

Alchrome 750 1Cr13Al4 1.0mm Thickness Fe Cr Al Alloy With 200mm Width 1



Alchrome 750 1Cr13Al4 1.0mm Thickness Fe Cr Al Alloy With 200mm Width 2



4. Why choose us

Shanghai Tankii Alloy Material Co., Ltd. specialized in production of the following:

Resistance Heating Alloy,

Nickel Chromium Alloy,

Iron Chromium Aluminum Alloy,

Nickel Aluminum Alloy,

Manganin,

Copper Nickel Alloy,

thermocouple wire,

pure nickel and other precision alloy materials in the form of round wire, ribbon wire, sheet, tape, strip, rod and plate.
Our products, such us nichrome wire, nichrome strip, fecral wire, fecral strip, thermocouple wire, nickel wire, nickel strip have been exported to Europe, USA, India, Southest Asia, South America,etc.
Welcome to call me or email to me for more info on resistohm strips, 1Cr13Al4 strip with good price.



1. Good Quality

2. Fast shipment

3. Small MOQ

4. Big Width for 1Cr13Al4 strip

5. Good reputation in the international market



Alchrome 750/ Alloy750/ Alferon902 1Cr13Al4 1.0 Mm Thickness Strip With 200mm Width
