Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire

Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire

    • Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire
    • Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire
    • Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire
  • Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire

    Product Details:

    Place of Origin: Shanghai, China,
    Brand Name: TANKII
    Certification: ISO SGS
    Model Number: Nickel Plated Copper Wire

    Payment & Shipping Terms:

    Minimum Order Quantity: Negotiable
    Price: negotiable
    Packaging Details: wooden case / Carton
    Delivery Time: 7-12 work days
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: 200 Tons per Month
    Contact Now
    Detailed Product Description
    Material: Silver Plated Copper Alloy Wire Diameter: 0.05mm
    Surface: Bright Color: Silver
    Coating Thickness(um): 0.3-5.0 Name: Silver Plated Copper Wire

    Enameled Tin / Nikcel / Silver Plated Copper Alloy Ribbon/ Flat Wire for cable



    Silver Plated Copper Alloy Wire

    Product standard: refer to JB / T 3135-2011, ASTM B289-99 or according to customer requirements

    Item Diameter(mm)
    0.016 0.02 0.025 0.03 0.04 0.05
    Tolerance(mm) ±0.001 ±0.001 ±0.002 ±0.002 ±0.002 ±0.002
    Conductivity(%) ≧70
    Elongation(%) ≧6 ≧10
    Tensile Strength(MPa) /
    Coating Thickness(um) ≧0.3
    Appearance No scratches, oil stains, exposed copper, oxidation, etc.
    Packing 3 inch, 5 inch, etc.
    Remark According to customers’ requirements

    Soft Wire





    Silver Plated Copper Alloy Wire-Hard Wire

    Item Diameter(mm)
    0.016 0.02 0.025 0.03 0.04 0.05
    Tolerance(mm) ±0.001 ±0.001 ±0.002 ±0.002 ±0.002 ±0.002
    Conductivity(%) ≧70
    Elongation(%) ≤4
    Tensile Strength(MPa) ≧700
    Coating Thickness(um) ≧0.2
    Appearance No scratches, oil stains, exposed copper, oxidation, etc.
    Packing 3 inch, 5 inch, etc.
    Remark According to customers’ requirements







    Silver Plated Copper Alloy Stranded Wire

    Item Diameter(mm)
    7/0.016 7/0.02 7/0.025 7/0.03 7/0.04 7/0.05
    Tolerance(mm) ±0.001 ±0.001 ±0.002 ±0.002 ±0.002 ±0.002
    Conductivity(Ωmm2/m) ≧70
    Strand 7
    Direction of Twist S(right)
    Elongation(%) ≤4(Hard)
    ≧5(Soft)
    Tensile Strength(MPa) ≧700(Hard)
    /(Soft)
    Coating Thickness(um) ≧0.2
    Appearance No scratches, oil stains, exposed copper, oxidation, etc.
    Packing Type 200
    Remark According to customers’ requirements

    Enameled Tin Copper Nickel Alloy Wire / Silver Plated Copper Alloy Ribbon Flat Wire
