Product Details
Place of Origin: Shanghai, China
Brand Name: Tankii
Certification: ISO9001:2015
Model Number: Copper
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiated price
Packaging Details: Spool in carton, if necessary with plywood pallet o plywood case or according to client´s requirements
Delivery Time: 7-12 DAYS
Payment Terms: L/C, T/T, Western Union, MoneyGram, Paypal
Supply Ability: 200+TON+MONTH
Conductor: |
Copper Alloy |
Temperature Class: |
130, 155, 180, 200, 220 |
Color: |
Yellow, Red, Green.... |
Enamel: |
Polurethane, Polyester, Polyimide... |
Enamel Thickness: |
Type I, Type II |
Conductor: |
Copper Alloy |
Temperature Class: |
130, 155, 180, 200, 220 |
Color: |
Yellow, Red, Green.... |
Enamel: |
Polurethane, Polyester, Polyimide... |
Enamel Thickness: |
Type I, Type II |
0.1mm 180 Degrees Red Color Polyuerthane Enameled Copper Wire/ Filament
| Enameled Type | Polyester | Modified Polyester | polyester-imide | Polyamide-imide | polyester-imide /Polyamide-imide |
| Insulation Type | PEW/130 | PEW(G)/155 | EIW/180 | EI/AIW/200 | EIW(EI/AIW)220 |
| Thermal class | 130, CLASS B | 155, CLASS F | 180, CLASS H | 200, CLASS C | 220, CLASS N |
| Standard |
IEC60317-0-2 IEC60317-29 MW36-A |
IEC60317-0-2 IEC60317-29MW36-A |
IEC60317-0-2 IEC60317-29 MW36-A |
IEC60317-0-2 IEC60317-29 MW36-A |
IEC60317-0-2 IEC60317-29 MW36-A |
Magnet wire or enameled wire is a copper or aluminum wire coated with a very thin layer of insulation. It is used in the construction of transformers, inductors, motors, generators, speakers, hard disk head actuators, electromagnets, electric guitar pickups and other applications that require tight coils of insulated wire.
The wire itself is most often fully annealed, electrolytically refined copper. Aluminum magnet wire is sometimes used for large transformers and motors. The insulation is typically made of tough polymer film materials rather than enamel, as the name might suggest.
Conductor
The most suitable materials for magnet wire applications are unalloyed pure metals, particularly copper. When factors such as chemical, physical, and mechanical property requirements are considered, copper is considered the first choice conductor for magnet wire.
Most often, magnet wire is composed of fully annealed, electrolytically refined copper to allow closer winding when making electromagnetic coils. High-purity oxygen-free copper grades are used for high-temperature applications in reducing atmospheres or in motors or generators cooled by hydrogen gas.
Aluminium magnet wire is sometimes used as an alternative for large transformers and motors. Because of its lower electrical conductivity, aluminium wire requires a 1.6-times larger cross sectional area than a copper wire to achieve comparable DC resistance.
