0.2*3 Bright Electric Resistance Wire , Flat Ribbon Good Flatness Flat Wire

0.2*3 Bright Electric Resistance Wire , Flat Ribbon Good Flatness Flat Wire

    • 0.2*3 Bright Electric Resistance Wire , Flat Ribbon Good Flatness Flat Wire
    • 0.2*3 Bright Electric Resistance Wire , Flat Ribbon Good Flatness Flat Wire
    • 0.2*3 Bright Electric Resistance Wire , Flat Ribbon Good Flatness Flat Wire
    • 0.2*3 Bright Electric Resistance Wire , Flat Ribbon Good Flatness Flat Wire
  • 0.2*3 Bright Electric Resistance Wire , Flat Ribbon Good Flatness Flat Wire

    Product Details:

    Place of Origin: Shanghai, China
    Brand Name: TANKII
    Certification: ISO9001:2008
    Model Number: 0Cr21Al6

    Payment & Shipping Terms:

    Minimum Order Quantity: 20kg
    Price: To negotiable
    Packaging Details: Spool, Coil, Carton, Wooden case, Palletwith plastic film as per client's requirements
    Delivery Time: 7-12 DAYS
    Payment Terms: L/C, T/T, Western Union, MoneyGram
    Supply Ability: 2000+TON+YEAR
    Contact Now
    Detailed Product Description
    Size: Required Shape: Flat Ribbon
    Colour: Silver Bright Feature: Stable Resistance, Flatness
    Sample: Stock Available Process: Rolled



    0.2*3 Bright Electric Resistance Flat Ribbon Good Flatness Flat Wire



    Specification:



    Alloy Type Diameter Resistivity Tensile Elongation
    (%)
    Bending Max.
    Continuous
    Working
    Life
    (mm) (μΩm)(20°C) Strength Times Service (hours)
    (N/mm²)   Temperature
    (°C)
    Cr20Ni80 <0.50 1.09±0.05 850-950 >20 >9 1200 >20000
    0.50-3.0 1.13±0.05 850-950 >20 >9 1200 >20000
    >3.0 1.14±0.05 850-950 >20 >9 1200 >20000
    Cr30Ni70 <0.50 1.18±0.05 850-950 >20 >9 1250 >20000
    ≥0.50 1.20±0.05 850-950 >20 >9 1250 >20000
    Cr15Ni60 <0.50 1.12±0.05 850-950 >20 >9 1125 >20000
    ≥0.50 1.15±0.05 850-950 >20 >9 1125 >20000
    Cr20Ni35 <0.50 1.04±0.05 850-950 >20 >9 1100 >18000
    ≥0.50 1.06±0.05 850-950 >20 >9 1100 >18000





    Series



    Alloy Nomenclature Performance Cr20Ni80 Cr30Ni70 Cr15Ni60 Cr20Ni35 Cr20Ni30
    Main Chemical composition Ni Rest Rest 55.0-61.0 34.0-37.0 30.0-34.0
    Cr 20.0-23.0 28.0-31.0 15.0-18.0 18.0-21.0 18.0-21.0
    Fe ≤1.0 ≤1.0 Rest Rest Rest
    Max. continuous service temp. of element(ºC) 1200 1250 1150 1100 1100
    Resistivity at 20ºC (μΩ·m) 1.09 1.18 1.12 1.0 1.04
    Density(g/cm3) 8.40 8.10 8.20 7.90 7.90
    Thermal conductivity (KJ/m·h·ºC) 60.3 45.2 45.2 43.8 43.8
    Coefficient of lines expansion(α×10-6/ºC) 18.0 17.0 17.0 19.0 19.0
    Melting point approx.( ºC) 1400 1380 1390 1390 1390
    Elongation at rupture(%) >20 >20 >20 >20 >20
    Micrographic structure austenite austenite austenite austenite austenite
    Magnetic properties nonmagnetic nonmagnetic Weak magnetic Weak magnetic Weak magnetic


    Nickel-chromium, nickel-chromium alloy with high and stable resistance, corrosion resistance, surface oxidation resistance is good, a better under high temperature and seismic strength, good ductility, good workability and weldability.



    Resistance wire is wire intended for making electrical resistors (which are used to control the amount of current in a circuit). It is better if the alloy used has a high resistivity, since a shorter wire can then be used. In many situations, the stability of the resistor is of primary importance, and thus the alloy's temperature coefficient of resistivity and corrosion resistance play a large part in material selection.

    When resistance wire is used for heating elements (in electric heaters, toasters, and the like), high resistivity and oxidation resistance is important.

    Sometimes resistance wire is insulated by ceramic powder and sheathed in a tube of another alloy. Such heating elements are used in electric ovens and water heaters, and in specialized forms for cooktops.






    Description: Ni35Cr20 ,also called Chromel D, Nikrothal 40, N4, Chromax, HAI-NiCr 40, Tophet D, Resistohm 40,

    Cronifer III, 35-20 Ni-Cr, Alloy D, Nikrothal 4, MWS-610, Stablohm 610,NiCr-D






    Unique technology and custom-made solutions

    We provide customed solutions to your problems with our unique

    technologies and well versed knowledge of materials acquired through

    our experience of manufacturing 50,000 items
    .




    Ability to add multiple features

    We are capable of adding a variety of features to metallic materials

    (resin coating, plating, bonding different kinds of metal, multigage skiving, etc.).


    0.2*3 Bright Electric Resistance Wire , Flat Ribbon Good Flatness Flat Wire0.2*3 Bright Electric Resistance Wire , Flat Ribbon Good Flatness Flat Wire
