Bright Bare Thermocouple Wire Extension Wire Solid Conductor Non Insulation

Bright Bare Thermocouple Wire Extension Wire Solid Conductor Non Insulation

    • Bright Bare Thermocouple Wire Extension Wire Solid Conductor Non Insulation
    • Bright Bare Thermocouple Wire Extension Wire Solid Conductor Non Insulation
    • Bright Bare Thermocouple Wire Extension Wire Solid Conductor Non Insulation
  • Bright Bare Thermocouple Wire Extension Wire Solid Conductor Non Insulation

    Product Details:

    Place of Origin: Shanghai, China
    Brand Name: TANKII
    Certification: ISO9001: 2015
    Model Number: Type K

    Payment & Shipping Terms:

    Minimum Order Quantity: 50kg
    Price: Negotiation
    Packaging Details: Spool, carton, plywod case with plastic film as clients required
    Delivery Time: 7-12 DAYS
    Payment Terms: L/C, T/T, Western Union, Paypal
    Supply Ability: 200+TON+MONTH
    Contact Now
    Detailed Product Description
    Type: K/S/B/N/J.. Insulation: Non
    Conductor: Solid Sample: Available
    Application: Cable Thermocouple Colour Insulated: Standard

    0.3mm Type K/S/B/N/J Thermocouple Bare Wire / Extension Wire

    Thermocouple Extension & Compensation Wire


    There are multiple types and grades of thermocouple wire.Each type of thermocouple wire has a specific combination of metal alloys.This combination is what defines the type of thermocouple.Thermocouple grade wire is used to manufacture thermocouple probes.Thermocouple grade wire is normally used for the junction and inside the stem sheath.



    Code
    +Positive leg
    -Negative leg
    N
    Ni-Cr-Si(NP)
    Ni-Si-Mg(NN)
    K
    Ni-Cr-Si(KP)
    Ni-Al(KN)
    E
    Ni-Cr(EP)
    Cu-Ni<constantan>(EN)
    J
    Iron(JP)
    Cu-Ni<constantan>(JN)
    T
    Copper(TP)
    Cu-Ni<constantan>(TN)
    B
    Platinum Rhodium-30%
    Platinum Rhodium-6%
    R
    Platinum Rhodium-13%
    Platinum
    S
    Platinum Rhodium-10%
    Platinum





    The thermocouple compensation cables can also be termed as instrumentation cables, since they are used for process temperature measurement. The construction is similar to pair instrumentation cable but the conductor material is different. Thermocouples are used in processes to sense temperature and is connected to the pyrometers for indication and control. The thermocouple and pyrometer are electrically conducted by thermocouple extension cables / thermocouple compensating cables. The conductors used for these thermocouple cables are required to have similar thermo-electric (emf) properties as that of the thermocouple used for sensing the temperature.

    Our plant mainly manufacture type KX,NX,EX,JX,NC,TX,SC/RC,KCA,KCB compensating wire for thermocouple, and they are used in temperature measurement instruments and cables. Our thermocouple compensating products are all made abiding by GB/T 4990-2010 'Alloy wires of extension and compensating cables for thermocouples' (Chinese National Standard), and also IEC584-3 'Thermocouple part 3-compensating wire' (International standard).



    Product Application

    Our company specializes in the production of thermocouple-related accessories. There are different specifications for heat-resistant and high-temperature shielding wires. If you need to place an order, please note that it takes several meters to contact customer service. We will place the order at the most favorable unit price and deliver it in time.









    Bright Bare Thermocouple Wire Extension Wire Solid Conductor Non InsulationBright Bare Thermocouple Wire Extension Wire Solid Conductor Non Insulation
