Enamelled Thermocouple K Type Wire For Standard Resistors DIN 250 Bobbin Size

Enamelled Thermocouple K Type Wire For Standard Resistors DIN 250 Bobbin Size

    • Enamelled Thermocouple K Type Wire For Standard Resistors DIN 250 Bobbin Size
    • Enamelled Thermocouple K Type Wire For Standard Resistors DIN 250 Bobbin Size
    • Enamelled Thermocouple K Type Wire For Standard Resistors DIN 250 Bobbin Size
    • Enamelled Thermocouple K Type Wire For Standard Resistors DIN 250 Bobbin Size
  • Enamelled Thermocouple K Type Wire For Standard Resistors DIN 250 Bobbin Size

    Product Details:

    Place of Origin: Shanghai, China
    Brand Name: TANKII
    Certification: ISO9001: 2015
    Model Number: Type K

    Payment & Shipping Terms:

    Minimum Order Quantity: 50kg
    Price: Negotiation
    Packaging Details: Spool, carton, plywod case with plastic film as clients required
    Delivery Time: 7-12 DAYS
    Payment Terms: L/C, T/T, Western Union, Paypal
    Supply Ability: 200+TON+MONTH
    Contact Now
    Detailed Product Description
    Bobbin Size: DIN 250 Bobbin Weight(with Wire): 19-20 KG
    Conductor Wire: Solid / Stranded Color: Natural, Green, Red...
    Temperature Range: 150, 180, 200 ℃ Insulation: Polyester



    Enamelled Type K Thermocouple Solid/ Stranded Wire for Medical Use

    roduct Description

    These enameled resistance wires have been broadly used for standard resistors, automobile
    parts, winding resistors, etc. using the insulation processing best suited for these applications, taking full advantage of the distinctive features of enamel coating.

    Furthermore, we will carry out enamel coating insulation of precious metal wire such as silver and platinum wire upon order. Please make use of this production-on-order.



    NiCr-NiSi (Type K) thermocouple bare wire



    NiCr NiSi (Type K) thermocouple bare wire finds the widest use in all base metal thermocouple, at temperature above 500°C.The main chemical composition of positive leg NiCr (KP) are Ni≈90% and Cr≈10%; negative leg NiSi (KN) are Ni≈97% and Cr≈3%. The operating temperature range is -200~1300°C(for short term) and 0~1100°C( for long term).

    Type K thermocouple bare wire has strong resistance to oxidation than other base metal thermocouple bare wire. It has high EMF against Platinum 67, excellent temperature accuracy, sensitivity and stability, with a low cost. It is recommended for oxidizing or inert atmospheres, but cannot be used directly in the following cases:
    (1) Alternatively oxidizing and reducing atmosphere,
    (2) Atmosphere with sulphur gases
    (3) Long time in vacuum
    (4) Low oxidizing atmosphere such as hydrogen and carbon monoxide atmosphere







    Type Of Bare Alloy Wire

    The alloy we can do enamelled are Copper-nickel alloy wire,Constantan wire,Manganin wire. Kama Wire,NiCr Alloy wire,FeCrAl Alloy wire etc alloy wire

    Size:

    Round wire:0.018mm~3.0mm

    Color of enamel insulation:Red,Green,Yellow,Black,Blue,Nature etc.

    Ribbon Size:0.01mm*0.2mm~1.2mm*24mm

    Moq:5kg each size



    Type of Insulation

    Insulation-enamelled Name

    Thermal Level℃

    (working time 2000h)

    Code Name GB Code ANSI. TYPE
    Polyurethane enamelled wire 130 UEW QA MW75C
    Polyester enamelled wire 155 PEW QZ MW5C
    Polyester-imide enamelled wire 180 EIW QZY MW30C
    Polyester-imide and polyamide-imide double coated enameled wire 200

    EIWH

    (DFWF)

    QZY/XY MW35C
    Polyamide-imide enamelled wire 220 AIW QXY

    MW81C





    Fundamental Parameter:



    Grade IEC ASTM DIN GOST
    K Cromel-Alumel Cromel-Alumel Cromel-Alumel Cromel-Alumel
    N Nicrosil-Nisil Nicrosil-Nisil Nicrosil-Nisil Nicrosil-Nisil
    E Cromel-Constantan Cromel-Constantan Cromel-Constantan Cromel-Constantan
    J Iron-Constantan Iron-Constantan Iron-Constantan Iron-Constantan
    T Copper-Constantan Copper-Constantan Copper-Constantan Copper-Constantan
    B PtRh30-PtRh6 PtRh30-PtRh6 PtRh30-PtRh6 PtRh30-PtRh6
    R PtRh13-Pt PtRh13-Pt PtRh13-Pt PtRh13-Pt
    S PtRh10-Pt PtRh10-Pt PtRh10-Pt PtRh10-Pt
    RC/SC Cu-CuNi (Copper-Coppernickel) Cu-CuNi (Copper-Coppernickel) Cu-CuNi (Copper-Coppernickel) Cu-CuNi (Copper-Coppernickel)
    KX Cromel-Alumel Cromel-Alumel Cromel-Alumel Cromel-Alumel
    NX Nicrosil-Nisil Nicrosil-Nisil Nicrosil-Nisil Nicrosil-Nisil
    EX Cromel-Constantan Cromel-Constantan Cromel-Constantan Cromel-Constantan
    JX Iron-Constantan Iron-Constantan Iron-Constantan Iron-Constantan
    TX Copper-Constantan Copper-Constantan Copper-Constantan Copper-Constantan




    Enamelled Thermocouple K Type Wire For Standard Resistors DIN 250 Bobbin Size
