High Temperature Heating Fe Cr Al Alloy Wire TK A-1 0.02 - 8.0mm Diameter

High Temperature Heating Fe Cr Al Alloy Wire TK A-1 0.02 - 8.0mm Diameter

    • High Temperature Heating Fe Cr Al Alloy Wire TK A-1 0.02 - 8.0mm Diameter
    • High Temperature Heating Fe Cr Al Alloy Wire TK A-1 0.02 - 8.0mm Diameter
    • High Temperature Heating Fe Cr Al Alloy Wire TK A-1 0.02 - 8.0mm Diameter
    • High Temperature Heating Fe Cr Al Alloy Wire TK A-1 0.02 - 8.0mm Diameter
  • High Temperature Heating Fe Cr Al Alloy Wire TK A-1 0.02 - 8.0mm Diameter

    Product Details:

    Place of Origin: Shanghai
    Brand Name: TANKII
    Certification: SGS ISO
    Model Number: TK A-1 / TKA1

    Payment & Shipping Terms:

    Minimum Order Quantity: 100KGS
    Price: 9.55-15USD/KG
    Packaging Details: Wooden case
    Delivery Time: 20days,
    Payment Terms: L/C, T/T, Western Union, paypal
    Supply Ability: 200 Tons per month
    Contact Now
    Detailed Product Description
    Color: Oxidized Golden, Bright Material: Fe Cr Al
    Diameter: 0.02-8.0mm Resistivity: 1.45
    Density(g/cm3): 7.1

    High-temperature Heating Alloy TK A-1

    High Temperature Heating Fe Cr Al Alloy Wire TK A-1 0.02 - 8.0mm Diameter

    TK A-1 large-sized cold-drawn wire products can be used for high-temperature resistance furnace. Practice has proved that: the product process is stable, integrated performance is good. Has good high temperature oxidation resistance and longer service life; excellent winding properties at room temperature processing, ease of processing molding; little rebound resilience and so on. Processing performance is very good; operating temperature can reach 1400 ℃.

    Main specifications and uses:



    Conventional Product specifications: 0.5 ~ 10 mm



    Uses: mainly used in powder metallurgy furnace, diffusion furnace, radiant tube heater and all kinds of high-temperature furnace heating body.



    MAIN CHEMICAL ELEMENTS AND PROPERTIES



    Properties Grade
        Cr Al   Re Fe
              25.0 6.0   Suitable Balance
    Max Continuous Service Temperature(ºC)   Diameter 1.0-3.0   Diameter large than 3.0,
      1225-1350     1400

    Resisivity 20ºC (ohm*mm2/m)       1.45
      Density(g/cm3)         7.1
    Approximate Melting Point( ºC)       1500
      Elongation (%)         16-33
    Repeatedly Bend Frequency(F/R) 20       7-12
    Continuous Service Time under 1350     More than 60 hours

    Micrographic Structure       Ferrite
    The relationship between the maximum operating temperature and the furnace atmosphere
    Furnace   Dry Air   Humid Air   hydrogen-argon Argon Decomposition
    atmosphere           gas       ammonia gas
    Temp(℃)   1400   1200   1400   950 1200



    User Manual



    • Rated Voltage: 220V/380V



    • The installation process to avoid knocking, to avoid the damp, hand-held stove wire, they should wear gloves. Wire should be installed after the furnace has remained flat, and prevent surface scratches, dirt, corrosion, or improper installation, by affecting the life of



    • In the rated voltage to use. In strong reducing atmosphere, acid atmosphere, an atmosphere of high humidity will affect the use of life;



    • Temperature before use should be in dry non-corrosive atmosphere, about 1000 ℃ spend a few hours, so that furnace wire protective film formed on the surface after normal use, so that can guarantee the normal life of furnace wire;



    • Furnace installation should ensure that the insulated wire good power to avoid touching furnace after the wire, guard against electric shock or burns.
