Nickel Silver Copper Precision Alloy Sheet / Strip / Wire C75400 C75200 C77000

Name: Nickel Silver Copper Precision Alloy Sheet / Strip / Wire C75400 C75200 C77000
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: C75400
Price: 499.05 USD
Availability: InStock

Product Details

Place of Origin: Shanghai, China

Brand Name: TANKII

Certification: ISO9001:2015

Model Number: C75400

Payment & Shipping Terms

Minimum Order Quantity: 20kg

Price: To be negotiated

Packaging Details: Spool, carton, plywood case according to requirements

Delivery Time: 7-12 DAYS

Payment Terms: L/C, T/T, Western Union, Paypal

Supply Ability: 30+TON+MONTH

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                      precision tubing, kovar alloy


Material:	Copper Based Alloy	Other Name:	German Silver, Argentan, New Silver, Nickel Brass, Albata, Alpacca
Standard:	ASTM, JIS, DIN, Etc	Composition:	Copper, Nickel, Zinc
Feature:	Corrosion Resistance,	Application:	Precision Instrument

Material:	Copper Based Alloy
Other Name:	German Silver, Argentan, New Silver, Nickel Brass, Albata, Alpacca
Standard:	ASTM, JIS, DIN, Etc
Composition:	Copper, Nickel, Zinc
Feature:	Corrosion Resistance,
Application:	Precision Instrument

Description

Nickel Silver Copper Precision Alloy Sheet / Strip / Wire C75400 C75200 C77000

Nickel Silver Copper Alloy Sheet/Strip/Wire (C75400 C75200 C77000)

1.General Introduction

Item name	Nickel sheet
Grade	Ni200, Ni201
Standard	ASTM B162
Manufacturing method	Cold rolled/Hot rolled
Dimension	Cold rolled	ThkWL (4.1-50)(300-3000)(500-7500)mm
	Hot rolled	ThkWL (0.3-4.0)(300-1400)(500-7500)mm
Condition	Cold Formed (Y)/ Half Hard (Y2)/ Soft (M)
Inspection	Chemical composition analysis, dimensional testing, tensile property inspection and visual surface inspection.
Main Clients	Asia Aluminum Co., Ltd, ISC Japan, GNG Korea etc
Application	electroplating, construction of the railroad, highway and so on, different kinds of mechanical equipment, electronics, battery, chemical processing, marine engineering

2.Properties

	Density	Melting point	Coefficient of expansion	Modulus of rigidity	Modulus of elasticity	Electrical resistivity
Ni200	8.9g/cm3	1446°C	13.3 µm/m °C (20-100°C)	81kN/mm2	204kN/mm2	9.6μW• cm
Ni201	8.9g/cm3	1446°C	13.1µm/m °C(20-100°C)	82kN/mm2	207kN/mm2	8.5μW• cm

3.Chemical Composition

Grade	Element Composition/%
Grade	Ni+Co	Mn	Cu	Fe	C	Si	Cr	S
Ni201	≥99.0	≤0.35	≤0.25	≤0.30	≤0.02	≤0.3	≤0.2	≤0.01
Ni200	≥99.0	/≤0.35	≤0.25	≤0.30	≤0.15	≤0.3	≤0.2	≤0.01
