Round Wire Fecral Alloy Resistance Heating Flat Wire With ISO9001 Certificate

Round Wire Fecral Alloy Resistance Heating Flat Wire With ISO9001 Certificate
Round Wire Fecral Alloy Resistance Heating Flat Wire With ISO9001 Certificate Round Wire Fecral Alloy Resistance Heating Flat Wire With ISO9001 Certificate Round Wire Fecral Alloy Resistance Heating Flat Wire With ISO9001 Certificate Round Wire Fecral Alloy Resistance Heating Flat Wire With ISO9001 Certificate

Large Image :  Round Wire Fecral Alloy Resistance Heating Flat Wire With ISO9001 Certificate

Product Details:
Place of Origin: China
Brand Name: Tankii
Certification: ISO 9001
Model Number: FeCrAl Alloy
Payment & Shipping Terms:
Minimum Order Quantity: 20 kg
Price: 5-7.5 usd / kg
Packaging Details: coil and spool
Delivery Time: 5-30 days
Payment Terms: T/T, Western Union
Supply Ability: 20000 kg / month

Round Wire Fecral Alloy Resistance Heating Flat Wire With ISO9001 Certificate

Description
Product Name: Fecral Alloy Round Wire Shape: Round Wire
Surface: Bright Or Black Material: Fecral
Size: Customzied Delivery: 5-30days
Highlight:

high resistance wire

,

nickel alloys

Fecral Alloy round wire Resistance Heating Flat Wire with ISO9001 Certificate



1) Material available:

Cr20Ni80, Cr30Ni70, Cr15Ni60, Cr20Ni35, Cr20Ni30, Cr20Ni25, NiCr25FeAlY, Cr13Al4, Cr21Al4, Cr14Al4, Cr20Al4, Cr21Al6, Cr23Al5, Cr25Al5, Cr21Al6Nb, Cr25Al5SE.


2) Shape:

Wire, strip, ribbon, sheet, coil


3) About us:

We can also design and manufacture according to your request. Shanghai Tankii Alloy Material Co., Ltd. is specialized in production of Ni-Cr Alloy, Cu-Ni Alloy, Fechral, thermocouple wire, pure nickel and other precision alloy materials in the form of wire, strip, rod, bar and plate.

4) Alloy character:

Ferritic alloys allow to reach process temperatures of 2192 to 2282F,
Corresponding to a resistance temperature of 2372F. All ferritic alloys have approximatively the same basis composition: 20 to 25 % of chromium, 4.5 to 6 % of aluminium, balance being iron. Some of them contain in addition rare earth, as yttrium or silicium. Those alloys having a ferritic structure, we observe, after a maintenance at high operating temperature, an important growth of the grain and a precipitation of chromium carbides at the grain joints level. This induces an increased embrittlement of the resistance, especially when it is come again at ambient temperature.

Specification:

Alloy Type Diameter Resistivity Tensile Elongation
(%)
Bending Max.
Continuous
Working
Life
(mm) (μΩm)(20°C) Strength Times Service (hours)
(N/mm²)   Temperature
(°C)
Cr20Ni80 <0.50 1.09±0.05 850-950 >20 >9 1200 >20000
0.50-3.0 1.13±0.05 850-950 >20 >9 1200 >20000
>3.0 1.14±0.05 850-950 >20 >9 1200 >20000
Cr30Ni70 <0.50 1.18±0.05 850-950 >20 >9 1250 >20000
≥0.50 1.20±0.05 850-950 >20 >9 1250 >20000
Cr15Ni60 <0.50 1.12±0.05 850-950 >20 >9 1125 >20000
≥0.50 1.15±0.05 850-950 >20 >9 1125 >20000
Cr20Ni35 <0.50 1.04±0.05 850-950 >20 >9 1100 >18000
≥0.50 1.06±0.05 850-950 >20 >9 1100 >18000
1Cr13Al4 0.03-12.0 1.25±0.08 588-735 >16 >6 950 >10000
0Cr15Al5 1.25±0.08 588-735 >16 >6 1000 >10000
0Cr25Al5 1.42±0.07 634-784 >12 >5 1300 >8000
0Cr23Al5 1.35±0.06 634-784 >12 >5 1250 >8000
0Cr21Al6 1.42±0.07 634-784 >12 >5 1300 >8000
1Cr20Al3 1.23±0.06 634-784 >12 >5 1100 >8000
0Cr21Al6Nb 1.45±0.07 634-784 >12 >5 1350 >8000
0Cr27Al7Mo2 0.03-12.0 1.53±0.07 686-784 >12 >5 1400 >8000

Round Wire Fecral Alloy Resistance Heating Flat Wire With ISO9001 Certificate 0Round Wire Fecral Alloy Resistance Heating Flat Wire With ISO9001 Certificate 1Round Wire Fecral Alloy Resistance Heating Flat Wire With ISO9001 Certificate 2Round Wire Fecral Alloy Resistance Heating Flat Wire With ISO9001 Certificate 3
