Product Details
Place of Origin: China
Brand Name: Tankii
Certification: ISO RoHS AISI ASTM GB
Model Number: 1J51,Ni50j
Payment & Shipping Terms
Minimum Order Quantity: 20Kg
Price: USD30/Kg
Packaging Details: Wooden Cases or Cartons
Delivery Time: 10-20 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 50Tons/Month
Surface: |
Bright |
Craft: |
Cold Rolled |
Sample: |
Free |
Shape: |
Strip/Wire/Ribbon/Pipe/Sheet/Bar/Foil |
Trade Term: |
FOB, EXW, CIF |
Density: |
8.2 |
Features:: |
Wear Resistant High Permeability Soft Magnetic All |
Surface: |
Bright |
Craft: |
Cold Rolled |
Sample: |
Free |
Shape: |
Strip/Wire/Ribbon/Pipe/Sheet/Bar/Foil |
Trade Term: |
FOB, EXW, CIF |
Density: |
8.2 |
Features:: |
Wear Resistant High Permeability Soft Magnetic All |
brand | Chemical composition | |||||||||
Ni | Mo | Mn | Co | Si | Cu ≤ |
Fe | C | P | S | |
≤ | ||||||||||
1j34 | 33.5~35.0 | 2.80~3.20 | 0.30~0.60 | 28.5~30.0 | 0.15~0.30 | 0.20 | Bal | 0.03 | 0.02 | 0.02 |
1j51 | 49.0~50.5 | - | 0.30~0.60 | - | 0.15~0.30 | 0.20 | Bal | 0.03 | 0.02 | 0.02 |
1j52 | 49.0~51.0 | 1.80~2.20 | 0.30~0.60 | - | 0.15~0.30 | 0.20 | Bal | 0.03 | 0.02 | 0.02 |
1j65 | 64.5~66.0 | - | 0.30~0.60 | - | 0.15~0.30 | 0.20 | Bal | 0.03 | 0.02 | 0.02 |
1j67 | 64.5~66.0 | 1.80~2.20 | 0.30~0.60 | - | 0.15~0.30 | 0.20 | Bal | 0.03 | 0.02 | 0.02 |
1j83 | 78.5~79.5 | 2.80~3.20 | 0.30~0.60 | - | 0.15~0.30 | 0.20 | Bal | 0.03 | 0.02 | 0.02 |
1j403 | 39.0~41.0 | 3.80~4.20 | 0.30~0.60 | 24.5~25.5 | 0.15~0.30 | 0.20 | Bal | 0.03 | 0.02 | 0.02 |
Physical properties
brand | Resistivity (μΩ·m) |
Density (g/cm³) |
Curie point (ºC) |
1j430 | 0.55 | 8.55 | 600 |
1j34 | 0.50 | 8.70 | - |
1j51 | 0.45 | 8.20 | 500 |
1j52 | - | 8.20 | - |
1j65 | 0.25 | 8.35 | 600 |
1j67 | 0.45 | 8.48 | 530 |
1j83 | 0.50 | 8.60 | 460 |
2.Usage
It is mostly used in small transformers, pulse transformers, relays, transformer, magnetic amplifier, electromagnetic clutch,the reactor coreand magnetic shielding which work inweak magnetic orsecondary magnetic field.
3.Features
1).Low coercivity and magnetic hysteresis loss;
2).High resistivity and loweddy-currentloss;
3).High initialmagnetic permeability and maximum magnetic permeability;
4).High saturation magnetic flux density;
4. Packing detail
1). Coil (plastic spool) + compressed ply-wooden case + pallet
2). Coil (plastic spool) + carton + pallet
5. Products and services
1). Pass: ISO9001 certification, and SO14001cetification;
2). Fine after-sale services;
3). Small order accepted;
4). Fast delivery;
