Product Details:
|
| Sample: | Free | Purity: | 78%Ni |
|---|---|---|---|
| Surface: | Bright | Standard: | GB/ASTM |
| Size: | 0.4X0.05mm 5.0x0.1mm | Application: | Heating / Resistor |
| Melting Point: | 1400 C | ||
| Highlight: | nickel alloys,nichrome resistance wire |
||
Flat Nichrome Electric Resistance Wire Chromel A Nikrothal 80 N8 MWS-650 Ribbon heating wire, 0.4X0.05mm 5.0x0.1mm
NiCr 80/20 :Chromel A, Nikrothal 80, N8, Nichrome V, HAI-NiCr 80, Tophet A, Resistohm
80, Cronix 80, Protoloy, Nikrothal 8, Alloy A, MWS-650, Stablohm 650
1--Product Description
Grade: Ni80Cr20
Resistivity: 1.09 ohm mm2/m
Chemical Composition: Nickel 80%, Chrome 20%
Condition: Bright, Annealed, Soft
Producer: Shanghai Tankii Alloy Material Co., Ltd.
Ni80Cr20 is a nickel-chromium alloy (NiCr alloy) characterized by high resistivity, good oxidation resistance and very good form stability. It is suitable for use at temperatures up to 1200°C,and hold a superior service life compared to Iron chromium alumium alloys.
Typical applications
Cooking:hot plates,domestic ovens,grills,toaster ovens,frying pans,deep fryers,rice cookers.
Water and beverage:boilers,immersion heaters,water kettles,coffee makers,dish washers,washing machines.
Space heating:radiators,storage heaters.
Others:irons,air heaters,oil heaters,glow plugs,sauna heaters
| Properties/Grade | Cr20Ni80 | Cr30Ni70 | Cr15Ni60 | Cr20Ni35 | Cr20Ni30 | |
| Main Chemical composition | Ni | Rest | Rest | 55.0-61.0 | 34.0-37.0 | 30.0-34.0 |
| Cr | 20.0-23.0 | 28.0-31.0 | 15.0-18.0 | 18.0-21.0 | 18.0-21.0 | |
| Fe | ≤1.0 | ≤1.0 | Rest | Rest | Rest | |
| Max. continuous service temp. of element | 1200 | 1250 | 1150 | 1100 | 1100 | |
| Resistivity at 20oC (μΩ·m) | 1.09 | 1.18 | 1.12 | 1.04 | 1.04 | |
| Density (g/cm3) | 8.40 | 8.10 | 8.20 | 7.90 | 7.90 | |
| Thermal conductivity(KJ/m·h·oC) | 60.3 | 45.2 | 45.2 | 43.8 | 43.8 | |
| Coefficient of lines expansion(α×10-6/oC) | 18.0 | 17.0 | 17.0 | 19.0 | 19.0 | |
| Melting point (approx.)( oC) | 1400 | 1380 | 1390 | 1390 | 1390 | |
| Elongation at rupture (%) | >20 | >20 | >20 | >20 | >20 | |
| Micrographic structure | austenite | austenite | austenite | austenite | austenite | |
| Magnetic properties | nonmagnetic | nonmagnetic | nonmagnetic | nonmagnetic |
nonmagnetic
|
|
Packaging & Shipping
Packaging: Products are generally supplied in standard cardboard boxes, pallets, wooden boxes. Special
packaging requirements can also be accommodated. (also depend on the customers' requirements)
For the Thermal spray wires, we pack the wires on spools. Then put spools into cartons, Then put the cartons onto pallet.
Shipping: We cooperation with many logistics company, We can provide express, sea transportation, air transportation, and rail way transportation based on customers' requirement.
Our service
(1) We can provide a free sample for testing but the freight at yours.
(2) Mill test certificate will be provided after production, If it is necessary.
(3) Good packing methods to keep goods no damage during delivery
(4) We cooperate with many famous forwarder, will try our best to choose the safty, convenience, quick, and cheap mode of transportation for our customers.
